UNPACKING THE PRINTER

Remove the printer from its carton being careful not to damage the packing material so that it may be re-used
if the printer is to be transported in the future.
Make sure that all the components illustrated in fig. 1 are present and that there are no signs of damage. If
there are, contact Customer Service.
1. Warning sheet
2. Cable
3. Paper roll
4. Adaptor / Battery recharger
5. Batteries (5 pcs.)
6. Belt coupler
7. Printer
8. Box

PRINTER FEATURES

The new s' print portable thermal printer offers an innovative alternative to impact-based systems, with a
range of interface options (RS232 serial, R232+IRDA, RS232+Bluetooth
powered using batteries.
The battery version (with RS232+IRDA interface) is primarily intended for the automatic identification and
mobile telephony market, combined with portable terminals without printer; the infrared bidirectional interface
with which it is equipped makes cable connection—so "inconvenient" for portable devices—unnecessary.
The BT version is powered by batteries (5 rechargeable AA penlight batteries), and communicates through
RS232 serial interface and Bluetooth
means of the Bluetooth ® wireless technology it is capable to print wireless at high speed without any
alignment. The ideal and best match of s'print-BT is together with PDAs, mobile phones, laptop computers,
and automatic ID devices.
The supported Bluetooth
®
emulation, and OPP (Object Push Profile) enabling the print-out of vCard format objects (business cards).
It is important to note that s' print is the first Custom printer designed with "sixload" easy paper load,
making it simpler and more convenient to use.
It has a 203 dpi thermal print mechanism that utilizes 57.5mm-wide paper rolls and can print up to 24 o 40
charaters per line.
DPT100-B/I/BT
(Fig. 1)
2
7
wireless technology. s'print-BT is a light weight and slim printer. By
®
technology profiles are SPP (Serial Port Profile) that provides RS232 serial cable
INTRODUCTION
1
3
8
wireless technology). The printer is
®
2
4
5
6
(1)
