Custom Engineering s'print User Manual page 13

2
remove the battery pack (2) by lifting the battery removal tape (1) (see fig. 1.6).
2
1
insert the 5 batteries (7) inside the compartment following the layout indicated in fig. 1.7 and re-position the
battery removal tape;
Note: when inserting the batteries, make sure the + and – signs are positioned correctly.
(7)
reclose the battery compartment by tightening the fastening screws.
DPT100-B/I/BT
1. INSTALLATION AND USE
A A B
1
1- 4
(Fig.1.5)
(Fig.1.6)
(Fig.1.7)
