Custom Engineering s'print User Manual page 38

devices ( for example mobile phone), which allow PINs entered, will not support
alphanumeric entry, devices sold with fixed PINs should be sold with a note of the PIN
given as decimal digits.
[Default]
[Reference]
[Example] • To reads the BT Name assigned to the printer send the following command :
The printer's answer is as follows (if BT Name is S'print BT) :
Printer
[ASCII]
• To set the printer's BT PIN parameter to '5678' send the following command :
Host
[ASCII]
The printer's answer is as follows :
Printer
[ASCII]
d ( ) d $ 1 B $ 4 D
[Name] Writes the value (dd) in the print mode
[Format] ASCII
Hex
Decimal
[Description] Sets the print mode default parameters:
$00 small character printing
$01 double width printing
$02 double height printing
$03 expanded printing
[Notes] • The setting is stored in the EEPROM
[Default] Setting by means of the front keys
[Reference] $1B $6D
[Example] For small character printing, transmit:
$30 $30 $1B $4D
For double height printing, transmit:
$30 $32 $1B $4D
$ 1 B $ 4 E
[Name] Set normal mode printing
[Format] ASCII
Hex
Decimal
[Description] Select normal mode printing:the receipt feeds out of the printer with the printing upside
down running from right to left
[Notes]
[Default] Setting in option register by means of front keys
[Reference] $1B $52
DPT100-B/I/BT
$06 $0B $53 $27 70
ACK 11 S ' p
$1B $42 $02 $05
ESC B m n
$06
ACK
dH dL
dH dL
dH dL
ESC N
1B 4E
27 78
3. PRINTER FUNCTIONS
$72 $69 $6E $74
r i n t
$35 $36 $37 $38
5 6 7 8
ESC M
1B 4D
27 77
3-8
$2D $42 $54 $00
- B T Null
$00
Null
