Options - Icom IC-F4029SDR Instruction Manual

D BATTERY PACK
Battery pack Voltage Capacity
BP-231 7.4 V 1150 mAh
BP-232 7.4 V 2000 mAh
Battery case for AAA
BP-240
(LR03) 6 alkaline
1
* Operating periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
2
* Operating period depends on the alkaline cells used.
D CHARGERS
•BC-119N
DESKTOP CHARGER
+ BC-145
AC ADAPTER
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 2 hours when BP-231 is attached.
•BC-121N - + AD-106
MULTI CHARGER
+ BC-157
AC ADAPTER
For rapid charging of up to 6 battery packs (six AD-106's are
required) simultaneously. An AC adapter should be pur-
chased separately. Charging time: approx. 2 hours when
BP-231 is attached.
•BC-160 + BC-145
DESKTOP CHARGER
For rapid charging of battery packs. The same as supplied
with the transceiver. An AC adapter is supplied with the
charger depending on versions. Charging time: approx. 2
hours when BP-231 is attached.
1
Battery life*
Analog mode 10.4 hrs.
Digital mode 8 hrs.
Analog mode 18 hrs.
Digital mode 14 hrs.
+ AD-106
CHARGER ADAPTER
(6 pcs.)
CHARGER ADAPTER
AC ADAPTER

OPTIONS

D BELT CLIPS
• MB-93
SWIVEL BELT CLIP
• MB-94
BELT CLIP
The same as supplied with the transceiver.
• MB-96N/96F
LEATHER BELT HANGER
D DC CABLES
• CP-17L
CIGARETTE LIGHTER CABLE
Allows charging of the battery pack through a 12 V cigarette
lighter socket. (For BC-119N)
• OPC-515L/OPC-656
DC POWER CABLES
Allows charging of the battery pack using a 13.8 V power
source instead of the AC adapter.
OPC-515L: For BC-119N
OPC-656 : For BC-121N
D OTHER OPTIONS
• SP-13
EARPHONE
Provides clear receive audio in noisy environment.
• HM-158L/159L -
SPEAKER MICROPHONE
Combination speaker-microphone that provides convenient
operation while hanging the transceiver from your belt.
• HS-94/HS-95/HS-97
HEADSET
HS-94: Ear-hook type
HS-95: Neck-arm type
HS-97: Throat microphone
VS-1L: VOX/PTT switch box for hands-free operation, etc.
Some options may not available in some countries. Please ask your
dealer for details.
13
+ VS-1L
VOX / PTT CASE
