I Digital mode indication
The following indications are available for the digital mode
operation.
• BREAK
: Appears when the break-in request call is
received.
• CANCELED : Appears when the break-in request call is
cancelled.
• COMPLETE : Appears when the break-in request call is
succeeded.
• FAILED
: Appears when a call (includes status or
break-in request call) is un-succeeded.
• HI VOLT
: Appears when the applied DC power voltage
exceeds the specified level.
• LOCK
: Appears when key (except [PTT]) operation
is performed while the lock function is acti-
vated.
• LOW BATT : Appears when the attached battery pack is
nearly exhaustion.
• STANDBY
: Appears when clear down signal is received.
• WAIT
: Appears when break-in request call is ready
to transmit.
DIGITAL OPERATION
7
7
24
