Icom IC-746 Instruction Manual page 29

(5) CW keyer set menu
F1 F2 F3
Set item up/down
SET MODE ITEM AND DEFAULT CONDITION
This menu is used to set the CW side tone, memory
keyer repeat time, dash weight, paddle specifications,
keyer type, etc.
F4 F5
This item sets the CW side tone.
• 0 to 100% in 1% steps can be selected.
This item sets the CW side tone level limit. When the
[AF] control is rotated above a specified level, the
CW side tone does not increase.
• OFF: CW side tone level is not limited.
• ON: CW side tone level is limited.
When sending CW using the repeat timer, this item
sets the time between transmissions.
• 1, 2, 10 or 30 sec. can be selected.
This item sets the dash/dot ratio.
• 1:1:2.8 to 1:1:4.5 (in 0.12 steps) can be selected.
This item sets the paddle polarity.
• Normal and reverse polarity can be selected.
This item sets the keyer type.
• ELEC-KEY, BUG KEY and Straight can be selected.
This item allows you to set the microphone [UP]/[DN]
switches to be used as a paddle.
• ON: [UP]/[DN] switches can be used for CW.
• OFF: [UP]/[DN] switches cannot be used for CW.
USING DIFFERENT OPERATING MODES
Push [F1] or [F2] to select the set contents.
Rotate the tuning dial to set the condition.
• See below for details.
Push [MENU] 2 times to return to regular operation
(M1).
DESCRIPTION
NOTE: When "ON" is selected, the frequency and
memory channel cannot be changed using the
[UP]/[DN] switches.
