6.2.3

Zone Bypass

There might be occasions when you need to temporarily bypass one or more zones before arming the system.
Bypass commands only work when the control panel is disarmed. For example, an open window can cause the
text keypad to display "Not Ready" followed by the zone number. The LED keypad might have one of its zone
LEDs on steady.
You must be in Single Partition Mode to bypass from a Master keypad. Bypassing without arming is not allowed
from an RF (wireless) keypad. If more than one zone requires bypassing, enter the additional zone numbers.
Refer to Section 6.2.2 Force Arming on page 13 for another method to bypass zones.
Table 11: Zone Bypass
Type of Command Sequence
Bypassing
Bypass Faulted [PIN][Bypass][XXX]
Zones [XXX][XXX] *
Read Bypassed [PIN][Bypass]
Zones
Clear Individual [PIN][Bypass][XXX] *
Bypassed
Zone(s)
Clear All [PIN][Bypass][*]
Bypasses
* [XXX] is a 3-digit zone
number
Bosch Security Systems | 6/05 | 4998154961B
What Happens
The green Status LED flashes if no other
zones are faulted.
• "Bypass" is displayed on a text keypad
followed by the zone number(s) of any
bypassed zones.
• All zones normally armed by the arming
command sequence are armed except
for faulted zones.
The specified individual zone bypass is
cleared.
All bypasses are cleared.
You must enter the zone number as a three-digit number. Example: 001, 062, or 125.
Note: All bypasses are cleared when the system is disarmed, except for 24-hour or Day-Monitor
zones. To clear a bypass on a 24-hour zone or Day-Monitor, use one of the two methods above.
EN | 14
What To Do
If desired, arm the control panel
after bypassing.
If desired, arm the control panel
after bypassing.
If desired, arm the control panel
after bypassing.
If desired, arm the control panel
after bypassing.
