Suitable locations for the electronics box:
Passenger side, next to the middle console under the paneling,
model-specific installation console (dealer).
Our suggested installation locations are shown in the illustration on
the right.
Further unsuitable locations are:
Leg and knee height, potential head impact zone, airbag inflation
space, engine compartment

6.2.3 Selection of the point of installation for the microphone

Suitable for the microphone:
Where voice can reach the microphone unhindered (distance between
the speaker and the microphone should be approx. 13.78 in), on the
A-column (between windshield and driver's side window), next to the
driver's sun visor, on the dashboard
Unsuitable for the microphone:
Close to the speakers (less than 31 in), under the dashboard, in the air
stream from open windows or air vents

6.2.4 Selection of site for installing the control unit with integrated display

Suitable for the control console:
In the space above the DIN installation shaft, close to the steering wheel (in an easily accessible and visible position)
Unsuitable for the control console:
Airbag inflation space, potential head impact zones, out of reach of driver's reach
EGO FLASH
Fig. 03:
Installation
locations
for the elec-
tronics box
Fig. 04:
Installation
location for
microphone
The illustration
shows one of
the potential mi-
crophone moun-
ting locations.
Alternatively,
the microphone
may be attached
to the sun visor
with the clip
provided.
