- Page 1 140 8001 1.02 English Bluetooth QD ID B013281...
-
Page 2: Table Of Contents
Switching on / off ..............................7.3.3 Pairing ..................................7.3.4 Automatic connection ............................. Calls ..................................10 7.4.1 Incoming call ................................10 7.4.2 Outgoing call ................................10 Volume ..................................10 Technical specifications __________________________________________________ 12 Certification ___________________________________________________________ 12 Conformity statement ____________________________________________________ 13 Hotline _______________________________________________________________ 15 EGO CUP... -
Page 3: Introduction / Foreword
Congratulations on your new EGO! EGO CUP is the clever beginners' solution for using your telephone in your vehicle: easy to operate, noble and compact. Installing the EGO CUP in the vehicle requires no special knowledge and skills. Simply place the EGO CUP on the adapter, engage with this while turning clockwise and finally insert into the cupholder while turning clockwise. -
Page 4: Safety Instructions
3 Safety instructions 1. Improper installation — Improper installation can cause damage to the device or vehicle! Only use EGO CUP in the cupholder! 2. Risk of injury — Installing the device in inappropriate positions may cause injuries in a road accident or render safety devices ineffective. -
Page 5: Scope Of Supply / Packaging Contents
4 Scope of supply / Packaging contents EGO CUP Adapter for use in the cupholder Microphone Connection kit for connection to the vehicle cigarette lighter (12 V) Quick Guide Safety instructions Only the connection kit included in the scope of supply (Funkwerk Dabendorf, model: R00020X7) is to be used. -
Page 6: Connection / Assembly
The function test cannot be carried out until the system has been connected to a compatible Bluetooth ® mobile phone. Please consult the “Putting into operation“ section further back in this instruction manual for details of the procedure. EGO CUP... -
Page 7: Operating Instructions
® handsfree profile. This means that the system can be used to operate telephones which support this profile. EGO CUP is the clever beginners solution for using your telephone in your vehicle and offers the following range of functions: Æ Call functions such as accept call, reject call and redial Æ... -
Page 8: Putting Into Operation
LED – functions An LED is integrated in the EGO CUP. This is used to display various states. The following states may occur. LED – state with inactive Bluetooth - connection ® Æ No mobile phone connected - LED flashes in intervals shortly LED –... -
Page 9: Switching On/Off
® telephone must be connected to the EGO CUP in order to be able to telephone with the system. You will learn how to do this in the following sections. If the system does not switch on after the connection kit is plugged in, activate the ignition of your vehicle. -
Page 10: Calls
IMPORTANT NOTE: Please observe the legal regulations of your country regarding use of the telephone in a vehicle! Volume The volume can be changed using the buttons. Pressing the button increases the volume and pressing the button lowers the volume. EGO CUP... -
Page 11: Troubleshooting
® Poor Bluetooth -connection Lower volume Audio sounds unpurified, scratchy The telephone is out of range Bring the telephone in range of the EGO CUP After switching on the ignition, ® ® The Bluetooth -interface is deactivated Switch Bluetooth to “ON” in your telephone... -
Page 12: Technical Specifications
8 Technical specifications EGO CUP dimensions 76 mm x 74 mm x 43,5 mm Length of adapter cable 0,6 m Operating voltage 12 V Temperature range -10 °C to +55 °C Supported Bluetooth ® profiles Handsfree 9 Certification 0681 In accordance with R&TTE Directive 1999/5/EC 03 5156 Model certification according to EU Directive 72/245/EEC (2006/28/EC) „Radio interference (electromagnetic... -
Page 13: Conformity Statement
Bluetooth ® is trademark of Bluetooth SIG, Inc. Funkwerk Dabendorf GmbH Märkische Straße D-15806 Dabendorf „EGO CUP“ handsfree system confirms that the is in compliance with the fundamental requirements and the other relevant guidelines of the EU Directive 1999/5/EC. 0681... - Page 14 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. EGO CUP...
-
Page 15: Hotline
11 Hotline Do you have questions or suggestions? Would you like more information? Do you require on-site consulting and service? Give us a call! Our hotline is available to you at the following times: Monday – Friday from 8.00 AM to 5.00 PM Please follow the steps below: Æ... - Page 16 Raytel Corporation A partner of Funkwerk Dabendorf GmbH 8820 Kenamar Drive, Ste 506 San Diego, CA 92121 Telephone 858.566.2159 858.566.2179 eMail support@egohandsfree.com A Funkwerk AG company. Internet www.egohandsfree.com Funkwerk Dabendorf reserves the right to modifications in the course of technological progress and deviations from the delivery scope! All rights reserved! Reproduction, in whole or in part, is only permitted with the prior written consent of Funkwerk Dabendorf GmbH!
