  • Page 1 130 8001 1.03 English Operating Manual...

  • Page 2: Table Of Contents

    6.1.1 Vehicle 6.1.2 Mobile phone 6.1.3 Muting (radio mute switch) 6.1.4 Converting the EGO LOOK into a previously installed Funkwerk hands-free car kit 6.1.5 Add-on speakers / Car audio telephone connection 6.1.6 Car radio line-in Installation locations 6.2.1 Checking cable lengths 6.2.2...
  • Page 3 Additional external speakers Connecting the components to the electronics box OPERATING INSTRUCTIONS Features 7.1.1 Overview of features Controls Getting started with the EGO LOOK controller Symbols 7.4.1 Symbols in the status bar 7.4.2 Speller symbols 7.4.3 Symbols for menu options 7.4.4...
  • Page 4 7.7.4 Call history 7.7.5 Voicemail 7.7.6 7.7.7 Music player 7.7.8 Dictation function 7.7.9 Settings Voice control SOFTWARE UPDATE SERVICE ACCESSORIES AND SPARE PARTS TECHNICAL SPECIFICATIONS CERTIFICATION CONFORMITY STATEMENT HOTLINE EGO LOOK...

  • Page 5: List Of Illustrations

    List of illustrations Fig. 01 Scope of delivery Fig. 02 Signal direction of the Bluetooth ® antenna Fig. 03 Installation location of the electronics box Fig. 04 Installation location of the microphone Fig. 05 Installation location of the radio controller Fig.

  • Page 6: Introduction / Foreword

    Before installation in your car, please make sure that your mobile phone is fully compatible with EGO LOOK. If you are uncertain, please consult your dealer or a qualifi ed workshop. Our service team will also be happy to help you with any information you may require.

  • Page 7: Safety Notes

    9. Interference with on-board electronics – Despite the extreme protection against interference, incorrect installation can lead to interference with the vehicle electronic systems. Please read the vehicle manufacturer’s notes to this effect! 10. Appropriate use – The EGO LOOK is intended exclusively for use in vehicles with Bluetooth ®...

  • Page 8: Scope Of Delivery / Package Contents

    Scope of Delivery PLEASE MAKE SURE THE CONTENT OF THE PACKAGE is complete. If any parts are missing, please don‘t hesitate to contact our service hotline team: (+1) 858.566.2170, Mon – Fri, 8 AM to 5 PM (PST) EGO LOOK...

  • Page 9: Installation Instructions

    6.1.1 Vehicle The EGO LOOK may only be installed in vehicles with 12 V, with the negative terminal connected to the chassis. If no car audio is installed, an add-on speaker will be required. For the installation of the optional charging cradle, you will require a model-specifi...

  • Page 10: Add-On Speakers / Car Audio Telephone Connection

    (block connector C), a 0.14 in jack socket or a RCA input socket. An appropriate adapter lead is required for the connection between the EGO LOOK line-out and the line-in version of your audio system. If your car audio system has no line-in option, you can employ the optionally available Stereo Mute Box for stereo reproduction in combination with your car’s front speakers.

  • Page 11: Selection Of Site For Installing The Microphone

    during installation, ensure that the antenna faces into the passenger cell (see Fig. 02). Vertical mounting is ideal. Metallic screening between the front panel and the passenger cell, such as metal or metallised plastic panels, are unsuitable and may ® interfere with the Bluetooth connection.

  • Page 12: Selection Of Site For Installing The Radio Controller

    Note the position of sunlight to avoid refl ection on the display The following locations are unsuitable for the display: Airbag infl ation space, potential head impact zones, out of Fig. 06: reach of driver’s reach Installation location of the display EGO LOOK...

  • Page 13: Installation

    Installation DAMAGE TO ESSENTIAL VEHICLE COMPONENTS! – Essential vehicle components or wiring can be damaged when drilling mounting holes or screwing in self-threading screws. Please make sure there is always suffi cient space behind the screw holes and drilled holes! 6.3.1 Mounting the electronics box Installation consoles for a number of car models are available from your...

  • Page 14: Inserting The Battery In The Radio Controller

    Position the latching tabs in the notches and rotate opposite the opening direction. 6.3.4 Mounting the radio controller Defi ne the mounting location The control console is mounted on a smooth service by means of the self-adhesive pad provided. Make sure that the user can easily reach the controller. EGO LOOK...

  • Page 15: Mounting The Display

    Cleaning and degreasing the mounting location The mounting location must be clean and free from grease and dirt/dust. Prior to installation, clean the area with a cleansing product containing ethyl alcohol. Only use cleansing products that do not damage plastics or varnished wood fi...

  • Page 16: Connection Scheme

    In order to access the phone input of your car audio system, the speaker output of your EGO LOOK must be connected to the phone input of your car audio system. The purple and green leads of the ISO cable must be connected to the car audio phone input for this option.

  • Page 17: Installing The Iso Connection Cable

    Fig. 09: Installation procedure Connect yellow mute lead to Connect EGO LOOK ISO connectors to car one of the three mute inputs wiring harness ISO connectors (see table) When the installation is completed, reconnect the grounding cable to the negative pole of the battery.

  • Page 18: Fig. 10 Setting The Pin According To Device Type

    Radio model Wire colour Function Mute Blaupunkt Permanent positive (30) blue Ignition (15) brown Ground (31) Socket contact housing Radio model Wire colour Function Mute Philips Permanent positive (30) blue Ignition (15) Fig. 12: brown Ground (31) Connection system EGO LOOK...

  • Page 19: Checking The Installation

    6.5.2 Checking the installation When the ISO connection cable is correctly installed, a call remains active until the call is ended, even if the ignition has already been turned off beforehand. The system switches off automatically when the call has been ended. If the system switches to off immediately switches off,then exchange the ignition lead (blue) with the power supply lead (red) as shown in Fig.

  • Page 20: Connecting The Components To The Electronics Box

    IMPORTANT: Only connect the device (MP3 player, iPod™, etc.) to the electronics box line-in with a jack cable when it is being powered by battery alone (without the recharger), as interfering impulses may otherwise cause damage to the electronic box line-in. EGO LOOK...

  • Page 21: Fig. 15 Connecting Electronics Box

    The electronics box line-out must be connected to the car audio line-in. Depending on the car audio line-in confi guration, one of the following cables is required: → Connection cable 0.14 in stereo jack to 0.14 in stereo jack (l = 4.92 ft) →...

  • Page 22: Operating Instructions

    7.1.1 Overview of features The hands-free EGO LOOK system supports the Bluetooth ® hands-free profile. The EGO LOOK is the convenient system for phoning in your car. It provides the following capabilities: → Call functions, such as incoming/outgoing calls, call waiting, alternate between calls, conference calling, and redial →...

  • Page 23: Controls

    Controls The EGO LOOK controller has three buttons. The picture to the right gives a brief overview of the device’s buttons. This section explains the functions of the individual buttons. Button functions You use the rotary knob to navigate through the menus and to select the active menu. Another function is the Voice control, which is activated by holding down the rotary knob.

  • Page 24: Getting Started With The Ego Look Controller

    NOTE: The EGO LOOK has a screensaver. After 60 seconds of inactivity, the brightness of the display is reduced. The display becomes brighter again after any button is pressed. At the same time, the button pressed performs the associated function.

  • Page 25: Symbols

    LED between the buttons is illuminated. → The controller has now been activated with the EGO LOOK and can be used. After changing the battery, it is unnecessary to perform the activation again.

  • Page 26: Speller Symbols

    Symbol for confi rming input Symbol to delete the last character Symbol for changing to numeric input Symbol for changing to lowercase letters Symbol for changing to uppercase letters Symbol for changing to special characters Symbol for exiting the speller EGO LOOK...

  • Page 27: Symbols For Menu Options

    7.4.3 Symbols for menu options Activated option. This symbol appears in front of an activated menu item. Deactivated option. This symbol appears in front of a menu item when it may be activated as an option. 7.4.4 Contact list number types Symbol for personal telephone numbers Symbol for mobile telephone numbers Symbol for business telephone numbers...

  • Page 28: Speller

    Take enough time to familiarize yourself with the use of the EGO LOOK in combination with your mobile phone. First of all, make a few calls to determine the ideal volume and the best voice pickup direction before using the EGO LOOK in traffi...

  • Page 29: About Bluetooth Technology

    7.6.3 On / Off function The fi rst time you use your EGO LOOK, you need to start it by switching on the ignition. You will see the start logo followed by the main screen. If the EGO LOOK is not connected to a mobile telephone, or if no user is found, the functionality of the main menu is limited.

  • Page 30: Entering The Bluetooth Pin

    7.6.6 Automatic coupling If the phone is already connected with the EGO LOOK, the EGO LOOK will try to couple to this phone. If the search is successful, a connection is automatically established. A search is always performed for the most recently connected mobile phone.

  • Page 31: The Menus

    The “Music player” menu allows you to playback songs and to control them as usual with Play, Pause, Stop, Forward, and Reverse. The playback device can be coupled to the EGO LOOK under “Options”. For details, see the “Music player”...
  • Page 32 You will fi nd more information in the „Call history“ chapter. → Messages Contains the list of text messages (SMS). Unread messages are marked accordingly. The messages menu is divided into “Read messages” and “New message”. More information can be found in the “Messages” chapter. EGO LOOK...
  • Page 33 Main menu structure for the EGO LOOK User management Settings Music player Dictation function Contacts list Call history Messages New user Ringtone Playback New recording Search Missed call Read message → → → → → → → User 1 - Melody...

  • Page 34: User Management

    To reach the Manage users function, go to the symbol on the main screen and press the rotary knob. Then, you will see the users linked to the EGO LOOK and the „New user“ item. If no users are linked, only the „New user“ item is present.

  • Page 35: Calling

    To delete all user data, open Manage users. Select the user to be reset. Confi rm your selection by pressing the rotary knob. A menu opens. In this menu, select the „Delete“ item. All user data is now deleted from the EGO LOOK.
  • Page 36 Call setup Call setup from the EGO LOOK is only possible if there is an existing Bluetooth ® connection between the EGO LOOK and the mobile phone. You may set up a call with voice-activated dialing or through the menu.
  • Page 37 You can also switch into Private mode during a telephone call by selecting the „Private mode“ item and confi rming with the rotary knob. The call now only uses the mobile telephone. Communication by way of the EGO LOOK is not possible at this moment and anyone else in the vehicle cannot listen to the conversation.

  • Page 38: Contacts List

    → Call waiting If the call waiting feature in your mobile phone and the EGO LOOK is switched on, while you are LOOKing to another person, incoming calls from third parties are signaled. The name or number of the third calling party is displayed, if possible.
  • Page 39 In the „Synchronize“ item, you can download the contact lists of the mobile telephone or from the SIM card into the EGO LOOK memory. Both contact lists can be synchronized, too. Once you have selected a contact list, you confi rm this with the rotary knob.

  • Page 40: Call History

    If for some reason the text message is not sent, the EGO LOOK informs the user and jumps back to “Edit text” mode. If the mobile phone does not support the sending of SMS messages via Bluetooth ®...

  • Page 41: Music Player

    EGO LOOK. In order to play back music, the EGO LOOK must be coupled to an A2DP-capable device (such as a mobile phone with A2DP, an iPod™ or an MP3-Player with A2DP adapter). Connection / coupling Under the “Option”...

  • Page 42: Dictation Function

    „Delete“ item. The recording is deleted by pressing the rotary knob. 7.7.9 Settings Symbol: The “Settings” menu is highly complex, since many settings for the EGO LOOK can be carried out under this menu item. The following settings can be carried out: → Ring tone →...
  • Page 43 → Follow-up time → Factory settings → Software update → Information → Help → Language → Voice control → Audio management → Voicemail → Power down Ring tone The „Ring tone“ menu is divided into „Melody“ and „Volume.“ Several ring tones are available under „Melody.“ You may set these according to your personal tastes.
  • Page 44 If this option is activated, rotating the knob counterclockwise signifi es advancing in the menu or the contact list. Delay time You may determine how long the EGO LOOK should remain active after switching off the ignition. The delay time may be set in steps between 0 and 30 minutes.
  • Page 45 Under certain circumstances, it may be necessary to adjust the microphone sensitivity. For example, if the microphone is located too far from or too close to the driver. The EGO LOOK has 10 possible sensitivity settings available. The sensitivities are shown to the right of the display as bars. There are a total of fi ve bars where one bar indicates two steps.

  • Page 46: Voice Control

    Voice control The dialogue-guided voice control of the EGO LOOK allows you to select a name or number via voice input. While numerical selection allows you to directly announce a number, you also have the option to select the name directly from the contacts list.
  • Page 47 This command may be used to select a name from the contacts list. The name must be contained in the contacts list for this command to function. If the name is not recognized or found, the EGO LOOK responds with “Please repeat”...
  • Page 48 To dial the phone number entered → “No / Back” To not dial the number entered → “Abort / Cancel“ Ends the dialogue without carrying out a function → “Help” Calls up Help and an explanation of possible commands EGO LOOK...
  • Page 49 “Show dialed numbers” This requires that numbers / names are included in the call list. If there is no entry, the EGO LOOK informs the user. The announcement can be stopped at any time by pressing the button. Afterwards, the following commands are available to you: →...
  • Page 50 “Show received calls” This requires that numbers / names are included in the call list. If there is no entry, the EGO LOOK informs the user. The announcement can be stopped at any time by pressing the button.
  • Page 51 “Store note / recording” This command initiates recording of a spoken note. The EGO LOOK checks if enough memory is available. The user can save the message and end the recording with the key. There is no command for ending the recording. Afterwards, the following commands may be given: →...
  • Page 52 “Help” As with “Cancel”, this command may be used at any time. If the “Help” command is selected, the EGO LOOK explains which commands are possible for specifi c functions at the time they are called up. “Redial / call again”...

  • Page 53: Software Update

    Software update The software for your EGO LOOK can be updated to the latest version via Bluetooth ® . In order to receive the most current software, please visit our website at www.fwd-online.de. A detailed description of the update procedure is included with...

  • Page 54: Service

    Dealers → Dealer search. 7. What is the procedure for transferring data in order to playback music? Data transfer is possible with the EGO LOOK in two ways (Bluetooth ® and Line-in). It is possible to make an MP3 player and iPod™...

  • Page 55: Troubleshooting

    Poor Bluetooth ® connection EGO LOOK or remove (metallic) obstructions if needed The mobile phone is not within range. Place the mobile phone within the range of the EGO LOOK The Bluetooth ® interface is Switch your mobile phone’s Bluetooth ®...

  • Page 56: Accessories And Spare Parts

    ® hands-free systems by Funkwerk Dabendorf. The charging cradle holds your mobile phone fi rmly and allows you to recharge its batteries in your car and is an ideal accessory for drivers who are constantly on the road and often need their phones.
  • Page 57 Replacement parts: Electronics box Display Controller Microphone Set of connecting cables Adapter cable T-Mobile...

  • Page 58: Technical Specifications

    Certifi cation 0681 Fully compliant with the EU R&TTE Directive 1999/5/EC 03 5074 Model certifi cation according to EU Directive 72/245/EWG (2006/28/EC) “Electromagnetic compatibility in motor vehicles” ® Bluetooth ® is a registered brand name of Bluetooth SIG, Inc. EGO LOOK...

  • Page 59: Conformity Statement

    Bluetooth SIG, Inc. Funkwerk Dabendorf GmbH Märkische Straße D-15806 Dabendorf Confi rms that the hands-free system “EGO LOOK” complies with the fundamental requirements and other relevant regulations of the EU Directive 1999/5/EC. 0681 FCC / IC statements This device complies with part 15 of the FCC Rules.
  • Page 60 (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTICE: Changes or modifi cations made to this equipment not expressly approved by Funkwerk Dabendorf may void the FCC authorization to operate this equipment.

  • Page 61: Hotline

    Hotline Any questions, comments, or suggestions? Would you like some more detailed information? Do you need an adviser or service in your area? Just give us a call! Our service hotline is there to help you during the following times: Monday–Friday from 8.00 a.m.
  • Page 62 A Funkwerk AG company Funkwerk Dabendorf reserves the right to modifi cations in the course of technological progress and deviations from the delivery scope! All rights reserved! Reproduction, in whole or in part, is only permitted with the prior written consent of Funkwerk Dabendorf GmbH!
