Page 1: Installation Instructions
128 8220 1.02 English Installation instructions Toyota Auris (Built from 2007) -
Page 2: Table Of Contents
On / Off function ......................15 5.8.2 Coupling ........................15 5.8.3 Automatic coupling ....................... 15 5.8.4 LED status ........................15 Troubleshooting ................16 Spares and accessories .............. 17 Technical specifications .............. 18 Certification ................18 Hotline ..................19 EGO TS... -
Page 3: Introduction / Preface
Introduction / Preface Congratulations on your new EGO! EGO TS is the intelligent entry-level solution for telephone use in your car: simple to operate, elegant and compact – with Bluetooth and audio enjoyment too. The installation of your EGO TS in your car requires specialist knowledge and skills. We recom- mend that the installation be carried out in a qualified professional workshop. -
Page 4: Safety Instructions
11. Damage caused by inappropriate replacement parts – Inappropriate spare or replacement parts may lead to malfunctions. Please use only the approved parts listed in the section „Spares and accessories“! Road safety risk – For your own safety, never initiate the coupling procedure while your vehicle is in motion! EGO TS... -
Page 5: Conformity Statement
Bluetooth SIG, Inc. ® The firm of Funkwerk Dabendorf GmbH Märkische Straße D-15806 Dabendorf herewith declares that the hands-free system „EGO TS“ in accordance with the essential requirements and other relevant provisions of the Directive 1999/5/EC. 0681... -
Page 6: Scope Of Delivery / Package Content
Scope of Delivery / Package content Electronics box À Control unit Á Microphone  Extension cable à Quick Guide Ä Á À Â Ä Ã EGO TS... -
Page 7: Installation Instructions
Installation instructions Improper Installation Improper installation may cause damages to the unit or to the vehicle! The installation of the hands-free car kit requires special knowledge and special abilities. Short circuits or cables connected in reverse polarity can cause severe damage to the unit. Ensure the vehicle’s battery is disconnected before you start the installation procedure. -
Page 8: Selection Of The Point Of Installation For The Microphone
Alternatively, the microphone may be attached to the sun visor with the clip provided. Unsuitable for the microphone: -Close to the speakers (less than 80 cm), under the dashboard, in the air stream from open windows or ventilator outlets EGO TS... -
Page 9: Mounting Components
Mounting Components DAMAGE TO ESSENTIAL VEHICLE COMPONENTS! Essential vehicle components or wiring can be damaged when drilling mounting holes or screwing in self-threading screws. Please make sure there is always sufficient space behind the screw holes and drilled holes! 5.3.1 Mounting the electronics box 130 mm Define the mounting points... -
Page 10: Connection Concept
In order not to cause any damage while dismantling the interior panelling it is advisable to use the so-called dismantling wedges! These leave no marks on the plastic parts! Remove the speedometer covering. Loosen the mounting screws and remove the speedometer unit. EGO TS... - Page 11 Carefully dismantle the panelling on the left and right next to the radio. Remove the ventilation unit and loosen the connector. Loosen the 2 screws each on the left and right next to the radio...
- Page 12 Pull the radio out of the slot carefully and remove the connectors of the radio. Connect the adapter cables specific for the car. Lay the connection line to the electronic box. Please pay attention to our explanatory notes on the point of installation of the electronic box in Chapter 5.2.2. EGO TS...
- Page 13 Choose a free installation slot for the EGO TS control unit. Carefully remove the covering and replace it by the control unit. * Control panel element on the left next to the steering wheel. Lay the microphone at a convenient spot, pay attention to our explanatory notes in Chapter 5.2.3.
-
Page 14: Functional Test
The procedure is explained in the sections „5.8. Getting started“. Symbols The control console of the EGO TS has a total of 4 keys. The illustration on the right shows an overview of the key locations. The functions of the individual keys are explained in the following section. -
Page 15: Getting Started
5.8.3 Automatic coupling If a phone is already connected with the system, the EGO TS tries to couple to this phone. When a connection has been successfully made, the two LEDs are permanently on. The connection is always made to the most recently coupled phone. If this phone is out of range, the system will search for other phones registered in the system. -
Page 16: Troubleshooting
EGO TS during coupling Reduce the distance between your Sound is unclear, dis- Poor Bluetooth connec- ® phone and the EGO TS or remove any tion torted (metallic) obstructions Make sure your phone is within the Phone is out of range. -
Page 17: Spares And Accessories
Spares and accessories Spares À Electronics box À Control unit Á Microphone  Extension cable à Á  à Accessories Specific vehicle connection cable Variant Vehicle Equipment Connecting cable Corolla E12 Standard MY2001>2004 Toyota DENGS-00982-07 Land Cruiser J12 Standard FWD 1284-01000 Hilux KUN 15/25 Option Wide2DIN (TNS310) Standard... -
Page 18: Technical Specifications
Profiles: Handsfree ® Certification 0681 Fully compliant with the EU R&TTE Directive 1999/5/EC Model certification according to EU Directive 72/245/EWG (2006/28/EC) “Electromagnetic com- patibility in motor vehicles” Bluetooth is a registered brand name of Bluetooth SIG, Inc. ® EGO TS... -
Page 19: Hotline
Hotline Any questions or suggestions? Would you like some more detailed information? Do you need an adviser or service in your area? Just give us a call! Our Hotline Team is there to help you at the following times: Monday–Thursday from 7.00 a.m. - Page 20 Funkwerk Dabendorf reserves the right to modifications in the course of technological progress and deviations from the delivery scope! All rights reserved! Reproduction, in whole or in part, is only permitted with the prior written consent of Funkwerk Daben- dorf GmbH!
