Unlocking The Scanner - Microtek ScanMaker i800 Plus Supplement Manual

Before you can operate the scanner, you will need to unlock the scanner and TMA.
To unlock the scanner, follow the steps below:
1. Remove the yellow "Step 3" sticker from your scanner.
2. With the scanner power off, tilt the back left corner of the scanner to see the
3. Push the locking switch to the position as indicated in the graphic below, with the
To unlock the TMA, follow the steps below:
1. Raise the scanner lid (TMA), then remove the yellow "Step 3" sticker from
2. Look for the locking switch at the base of the TMA.
3. Push the locking switch to the position as indicated in the graphic below, with the
4 ScanMaker i800 Plus Supplement

Unlocking the Scanner

locking switch at the bottom.
icon on the lock showing as "unlocked".
the TMA.
icon on the lock showing as "unlocked".
Unlocked
Unlocked
