Calibration and Profiling

After the Preview, you are now ready to complete calibration and create a profile for
your scanner.
1. Scan the target. To do this, select the entire target by dragging a frame over it, and
2. Align the registration marks of the target with your cursor (see inset at bottom
3. Click the Create Profile button (PC) or Finish button (Mac) to create the scanner
Aligning the Registration Marks
A. Upper-left registration mark
Move the cursor to the target image
area; the pointer will change to a
horizontally flipped L mark ("
Align the cursor with the small upper-
left registration mark.
then click the Next>> button.
of page).
ICC profile. At the end of the profiling process, a dialog box appears, prompting
you to enter a profile name and description.
B. Upper-right registration mark
After the upper left mark is aligned,
the upper right part of the target image
"). is displayed, and an instruction dialog
box prompts you to align the upper
right registration mark.
Move the cursor to the target image
area; the pointer will change to a
normal L mark ("
with the small upper-right registration
mark.
C. Bottom-right registration mark
After the upper right mark is aligned,
the lower right part of the target
image is displayed, and an instruction
dialog box prompts you to align the
bottom-right registration mark.
Move the cursor to the target image
area; the pointer will change to a
"). Align the cursor vertically flipped L mark ("
the cursor with the small bottom-
right registration mark.
ScanMaker i800 Plus Supplement
"). Align
