ScanMaker i900
Installing and Getting Started
Introduction ............................................................................................................... 2
System Requirements ............................................................................................... 2
Unpacking the Scanner ............................................................................................. 3
Taking a Closer Look ................................................................................................. 4
Unlocking the Scanner .............................................................................................. 5
Installing the Scanner Software ............................................................................... 6
Connecting the Scanner to Your Computer ............................................................. 7
Trademarks
Microtek
®
, ScanMaker
TM
,
and ScanWizard
®
trademarks or registered
Positioning Reflective Originals ............................................................................. 10
trademarks of Microtek
International, Inc. DIGITAL
Positioning Transparent Film .................................................................................. 11
ICE is a trademark of Kodak.
®
®
Macintosh
and Apple
are
registered trademarks of
Apple Computer, Inc.
®
Windows
is a registered
trademark of Microsoft
Corporation. All other
products or name brands
are trademarks of their
respective holders.
Important
Documents you scan may
Your First Scan ........................................................................................................ 18
be protected under
copyright law. The
unauthorized use of such
documents could be a
violation of the rights of the
copyright holder. Microtek
Specifications .......................................................................................................... 22
bears no responsibility for
the unauthorized use of
copyrighted materials.
Copyright© 2003 Microtek International, Inc. http://www.microtek.com
I49-003620 A, October 2003
Contents
Shipping scanner ............................................................................................... 5
Using the FireWire Cable .................................................................................. 7
Using the Hi-Speed USB Cable ......................................................................... 8
Using the Glass Holder .................................................................................... 12
Using the Other Film Holders ......................................................................... 13
A. Using the 35mm Slide Holder ............................................................. 14
B. Using the 35mm Filmstrip Holder ....................................................... 14
C. Using the 120 Film Holder ................................................................... 16
D. Using the 4 " x 5 " Film Holder .............................................................. 17
A. Scanning Regular, Non-Damaged Photos ................................................. 18
B. Scanning Damaged Photos ........................................................................ 19
C. Scanning Transparent Film ......................................................................... 21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ScanMaker i900 and is the answer not in the manual?

Questions and answers

Related Manuals for Microtek ScanMaker i900

Summary of Contents for Microtek ScanMaker i900

  • Page 1: Table Of Contents

    C. Scanning Transparent Film ................. 21 copyright holder. Microtek Specifications ......................22 bears no responsibility for the unauthorized use of Federal Communications Commission Interference Statement ......23 copyrighted materials. Copyright© 2003 Microtek International, Inc. http://www.microtek.com I49-003620 A, October 2003...

  • Page 2: Introduction

    ScanWizard 5. Introduction The ScanMaker i900 is a 48-bit, high-speed color scanner featuring a dual interface (FireWire and Hi-Speed USB), 6400 x 3200-dpi optical resolution, and two scanning beds — an upper bed for scanning reflective materials such as photos and prints, and a lower bed for scanning transparent materials such as film, slides, and filmstrips.

  • Page 3: Unpacking The Scanner

    3-5. 4 " x 5 " Film Holder 2-4. Power cord 3-6. Main Holder 2-5. Microtek CD-ROM (ScanWizard 5) 3-7. Vinyl Strip (10 pcs) 2-6. Documentation: Includes ScanMaker i900 Installing and Getting Started, ScanWizard 5 Quick Reference Guide, and other inserts ScanMaker i900 Installing and Getting Started...

  • Page 4: Taking A Closer Look

    Scanner lid Glass surface (Upper scan bed) Vertical ruler Power button Horizontal ruler Power indicator (green) Reflective Ready indicator (amber) Transparency Ready indicator (amber) Accessory port FireWire port (1) USB 2.0 port (1) Power connector ScanMaker i900 Installing and Getting Started...

  • Page 5: Unlocking The Scanner

    When the screw has been tightened, this indicates that your scanner is locked. 4. Turn off your scanner. The scanner is now ready for transport. ScanMaker i900 Installing and Getting Started...

  • Page 6: Installing The Scanner Software

    Do not turn off your computer during software installation. 4. Click EXIT on the Microtek Software Installer screen when all the software has been installed. 5. Install the image-editing software application, which is on a separate CD-ROM included in your scanner package.

  • Page 7: Connecting The Scanner To Your Computer

    Connecting the Scanner to Your Computer The ScanMaker i900 comes with both FireWire and Hi-Speed USB built-in interfaces. You may choose either FireWire (IEEE-1394) or Hi-Speed USB as the interface for connection between the scanner and computer. (You can use only one interface at a time.)

  • Page 8: Are Using The Hi-Speed Usb Cable

    1. Plug the power cord into the back of the scanner, and plug the other end into a power source (power surge protector highly recommended). Note: Make sure no other cable is connected to the scanner except the power cord at this point. ScanMaker i900 Installing and Getting Started...
  • Page 9 3. Press the power button on the front panel of Power button the scanner, and wait for the lights to stop blinking and stay on steady. The scanner will be detected by your system automatically. ScanMaker i900 Installing and Getting Started...

  • Page 10: Positioning Reflective Originals

    Positioning Reflective Originals This procedure applies when you use the upper scan bed of the ScanMaker i900. The upper scan bed is used for scanning reflective materials such as photos and prints. 1. Open the scanner lid. 2. Place the original to be scanned face down on the scanner’s glass surface. Center the top of the original along the horizontal ruler on the scanner.

  • Page 11: Positioning Transparent Film

    Positioning Transparent Film This procedure applies when you use the lower scan bed of the ScanMaker i900, which has a holder that is used for scanning transparent film. There are two ways to scan transparent film: A. By using the Glass Holder, which is used to scan non-standard-sized transparent film.

  • Page 12: Using The Glass Holder

    3. Insert the holder all the way into the transparency bay (the drawer or lower compartment) of the scanner. Note: The glass holder requires regular cleaning. To clean, use mild glass cleaning solution, and wipe the glass plate gently with lint-free lens-cleaning cloth to prevent leaving fiber residues. ScanMaker i900 Installing and Getting Started...

  • Page 13: Using The Other Film Holders

    For instance, use the 4" x 5" film holder to scan 4" x 5" film, or use the 35mm filmstrip holder to scan 35mm filmstrips. 35mm Slide Holder 35mm Filmstrip Holder 120 Film Holder 4” x 5” Film Holder Main Holder ScanMaker i900 Installing and Getting Started...

  • Page 14: Using The 35Mm Slide Holder

    Two strips of six frames can be mounted into the 35mm Filmstrip Holder at a time. 1. Place the 35mm filmstrip into the holder. a) Push to open the lid. b) Place the 35mm filmstrip into the holder. ScanMaker i900 Installing and Getting Started...
  • Page 15 (the drawer or lower compartment) of the scanner. Caution: When the filmstrips are closed, do not move or touch the filmstrips. If you do so, this will bend the original that may result in out-of-focus scans. ScanMaker i900 Installing and Getting Started...

  • Page 16: Using The 120 Film Holder

    Pull down the side to close the lid. 2. Put the film holder into the transparency tray. 3. Insert the whole assembly into the transparency bay (the drawer or lower compartment) of the scanner. ScanMaker i900 Installing and Getting Started...

  • Page 17: Using The 4 " X 5 " Film Holder

    Pull down the side to close the lid. 2. Put the film holder into the transparency tray. 3. Insert the whole assembly into the transparency bay (the drawer or lower compartment) of the scanner. ScanMaker i900 Installing and Getting Started...

  • Page 18: Your First Scan

    • Contains the built-in ScanWizard 5 help • Exits ScanWizard 5 • Minimizes ScanWizard 5 (Windows only) Resize dotted line scan frame for size of the actual scan Selections and options for image settings ScanMaker i900 Installing and Getting Started...

  • Page 19: Scanning Damaged Photos

    This feature is for Windows and Mac OS X only; see the ScanWizard 5 manual provided in the Microtek CD-ROM for more details. 1. Raise the scanner lid, then place the damaged photo to be scanned face down on the scanner glass surface.
  • Page 20 Standard Control Panel Before After Note: Microtek is always working to enhance ScanWizard 5. For the most recent version of ScanWizard 5 with the latest enhancements, visit www.microtekusa.com and download the most current driver. ScanMaker i900 Installing and Getting Started...

  • Page 21: Scanning Transparent Film

    Preferences button, uncheck the option “Automatically previews scan bed when launching ScanWizard 5” from the dialog box. If unchecked, no auto-preview image is carried out when ScanWizard 5 is launched. ScanMaker i900 Installing and Getting Started...

  • Page 22: Specifications

    Relative Humidity: 20% to 85% *Please note: Hi-Speed USB (USB 2.0) is a new standard which is backward compatible with USB 1.1. To achieve Hi-Speed USB throughput speeds, a Hi-Speed USB supported system is required. ScanMaker i900 Installing and Getting Started...

  • Page 23: Federal Communications Commission Interference Statement

    Responsible Party: Loi Han Tested to Comply With FCC Standards Microtek Lab, Inc. 16941 Keegan Avenue FOR HOME OR OFFICE USE Carson, CA 90746 Phone: 310-687-5800 Fax: 310-687-5950 ScanMaker i900 Installing and Getting Started...
