Adjustable ASBA Standard Seat
Invacare Adjustable ASBA Power Tilt Only
Invacare Adjustable ASBA Formula™ PTO Plus
Power Wheelchair Base
User Manual
EN
Advertisement
Table of Contents
Related Manuals for Invacare Adjustable ASBA Seats
Summary of Contents for Invacare Adjustable ASBA Seats
- Page 1 Invacare Adjustable ASBA Seats ® Invacare Adjustable ASBA Standard Seat Invacare Adjustable ASBA Power Tilt Only Invacare Adjustable ASBA Formula™ PTO Plus Power Wheelchair Base User Manual This manual MUST be given to the user of the product. BEFORE using this product, read this manual and save for future reference.
- Page 2 © 2011 Invacare Corporation. All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prior written permission from Invacare. Trademarks are identified by ™ and ®. All trademarks are owned by or licensed to Invacare Corporation or its subsidiaries unless otherwise noted.
-
Page 3: Table Of Contents
Operation Information ............................................16 Setup ................................................. 16 Transport................................................. 17 Powered Seating............................................. 18 Repair or Service Information ........................................19 Safety/Handling ..............................................20 Pinch Points..............................................21 Stability and Balance ............................................22 Footplates and Front Rigging........................................22 Part No 1143192 Invacare® Adjustable ASBA Seats... - Page 4 Programmable Mono Ports 1 and 2 with External Mode Switch............................36 Remote On/Off Switch ..........................................36 Mode Switch ..............................................37 Memory Card Slot ............................................37 About Front Riggings ............................................38 Installing/Removing Footrests..........................................38 PH904A, PHAL4A, 70° and PW93......................................38 70° Taper .................................................39 Raising/Lowering Elevating Front Riggings ......................................39 Invacare® Adjustable ASBA Seats Part No 1143192...
- Page 5 Operating the Manual Recliner Option ......................................48 Operating the Manual Tilt Option (TDX Spree Only) ................................49 ADJUSTMENT Footrest Height Adjustment ..........................................51 PH904A and PHAL4A Front Riggings ....................................... 51 70° and PW93 ..............................................52 70° Taper................................................. 53 Part No 1143192 Invacare® Adjustable ASBA Seats...
- Page 6 Six Month Inspection .............................................65 Replacing Heel Loops ............................................66 Adjusting/Replacing Telescoping Front Rigging Support ................................67 Installing Adjustable Angle Flip-up Footplate Hinge ..................................68 Installing Adjustable Angle Flip-up Footplates....................................69 Composite/Articulating Footplate Heel Loop Replacement ..............................70 Disassembly ..............................................70 Assembly................................................70 Invacare® Adjustable ASBA Seats Part No 1143192...
- Page 7 Adjusting Headrest Depth/Direction ......................................76 Replacing Headrest.............................................. 76 Replacing Back or Headrest Upholstery ......................................77 Replacing Back Upholstery .......................................... 77 Replacing Headrest Upholstery........................................77 Removing/Installing the Manual Tilt Release Lever from the Stroller Handle ........................78 Part No 1143192 Invacare® Adjustable ASBA Seats...
-
Page 8: General
Caution indicates a potentially hazardous situation which, if not avoided, may result in property damage or minor injury or both. IMPORTANT Indicates a hazardous situation that could result in damage to property if it is not avoided. Gives useful tips, recommendations and information for efficient, trouble-free use. Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 9: Reference Documents
Refer to the table below for part numbers of additional documents which are referenced in this manual. MANUAL PART NUMBER MK6i™ Electronics Programming Guide 1141471 Adjustable ASBA Service Manual 1143238 PTO Plus Service Manual 1125031 Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 10: Global Limited Warranty (Excluding Canada)
This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state. Invacare warrants the seat frame to be free from defects in materials and workmanship for a period of three (3) years from the date of purchase from Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty. -
Page 11: Canada Limited Warranty
This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state. Invacare warrants the seat frame to be free from defects in materials and workmanship for a period of three (3) years from the date of purchase from Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty. -
Page 12: Label Locations
Serial Number Located HERE WA R N I N G Refer to Service Manual to reposition the seat - otherwise serious personal injury and damage will result. P/N 1114823 Rev B - 5/10/06 Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 13: Wheelchairs With Trro
2 LABEL LOCATIONS Wheelchairs with TRRO Wheelchairs without TRRO Auto style seat positioning strap shown. This label is also on the airline style seat positioning strap. Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 14: Pronto ® M91™ With Formula Pto Plus Seating System
2 LABEL LOCATIONS ® Pronto M91™ with Formula PTO Plus Seating System Rear View of Actuator Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 15: Safety
NOTICE THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. Check all parts for shipping damage and test before using. In case of damage, DO NOT use. Contact Invacare/Carrier for further instruction. As a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of wheelchairs to meet many needs of the end user. -
Page 16: Operation Information
After the wheelchair has been set-up/adjusted, check to make sure that the wheelchair performs to the specifications entered during the set-up procedure. If the wheelchair does not perform to specifications, turn the wheelchair Off immediately and reenter set-up specifications. Repeat this procedure until the wheelchair performs to specifications. Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 17: Transport
As of this date, the Department of Transportation has not approved any tie-down systems for transportation of a user while in a wheelchair, in a moving vehicle of any type. It is Invacare’s position that users of wheelchairs should be transferred into appropriate seating in vehicles for transportation and use be made of the restraints made available by the auto industry. -
Page 18: Powered Seating
Such devices may result in excess heating and cause damage to the actuator and associated wiring and could cause a fire, death, physical injury or property damage. If such devices are used, Invacare shall not be liable and the limited warranty is void. -
Page 19: Repair Or Service Information
If tilt function is not operating and is in the down (seated) position, PRIOR to servicing the device, refer to the seating system service manual, part number 1125031, or contact Invacare Technical Services for instructions on how to safely service the tilt system, actuator or spring assist module. Call 800-832-4707. -
Page 20: Safety/Handling
DO NOT use if joystick does not spring back to the neutral position or becomes sticky or sluggish. DO NOT use if joystick boot is torn or damaged. ALWAYS check foam grips for looseness before using the wheelchair. If loose, contact a qualified technician for instructions. Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 21: Pinch Points
Full Full Tilt Telescoping Tube Upright Position Position Walking Beam Pinch Point Walking Headtube Cap Beam Headtube Cap (Not Shown) Front Caster Front Caster Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 22: Stability And Balance
Reaching, Bending - Backward WARNING DO NOT lean over the top of the back upholstery. This will change your center of gravity and may cause you to tip over. Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 23: Transferring To And From Other Seats
WARNING Invacare DOES NOT recommend the use of its wheelchairs as a weight training apparatus. Invacare wheelchairs have NOT been designed or tested as a seat for any kind of weight training. If occupant uses said wheelchair as a weight training apparatus, INVACARE SHALL NOT BE LIABLE FOR BODILY INJURY AND THE WARRANTY IS VOID. -
Page 24: Electromagnetic Interference (Emi) From Radio Wave Sources
Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM radios, TV sets, CD players, cassette players, and small appliances, such as electric shavers and hair dryers, so far as we know, are not likely to cause EMI problems to your powered wheelchair. Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 25: Powered Wheelchair Electromagnetic Interference (Emi)
2) This device has been tested to a radiated immunity level of 20 volts per meter. 3) The immunity level of the product is unknown. Modification of any kind to the electronics of this scooter as manufactured by Invacare may adversely affect the EMI immunity levels. -
Page 26: Technical Data
1-inch increments (Back Post Only) Seat-to-Floor Height 18 to 20 inches ± ¼ 0° Seat Angle: 18.25 ± inch .25 inches 5° Seat Angle: 19.25 ± .25 inches *16-inch deep frame with AT5544 Legrests Invacare® Adjustable ASBA Seats Part No 1143192... - Page 27 Upholstery Options: Nylon Seat Cushion: Cushion (Optional) Front Riggings: Center mount, Swingaway, Manually Elevating, Power Elevating Footrests: Telescoping Front Rigging Supports, 2-inch and 4-inch long Pivot Slide Tube *16-inch deep frame with AT5544 Legrests Part No 1143192 Invacare® Adjustable ASBA Seats...
-
Page 28: Weight
Example: If weight limitation of the wheelchair is 300 lbs and additional items equal 25 lbs, subtract 25 lbs from 300 lbs this means the maximum weight limitation of the user is 275 lbs. Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 29: Usage
Tube Slide joystick mounting tube to the desired position. Adjustment Lock Turn the adjustment lock lever to secure the adjustment lock to the Lever joystick mounting tube. FIGURE 1 Preparing the Joystick for Use Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 30: A Note About Drive Lock-Out
This may affect the wheelchair user’s line of sight while driving. Make sure the wheelchair user can see properly to ensure safe driving. *20° back angle can be any combination of tilt, back angle and/or surface angle. Refer to Typical Product Parameters on page 26 for tilt angle ranges. Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 31: Operating Powered Seating Systems
Such devices may result in excess heating and cause damage to the actuator and associated wiring and could cause a fire, death, physical injury or property damage. If such devices are used, Invacare shall not be liable and the limited warranty is void. -
Page 32: Using The Powered Seating Switch
Press the mode button to switch from driving mode to tilt mode. The LED will light up with a circle around it. Move the joystick: • Forward - Tilts the seat back. • Backward - Tilts the seat upright. Invacare® Adjustable ASBA Seats Part No 1143192... - Page 33 Additional Input for GREEN LED Service Indicator Powered Seating Switch Charger/ Active Programming (If Programed) Input *The mode button is only present on SPJ+ w/ACC joystick. FIGURE 2 Using the MK6i SPJ+ w/ACC Joystick Part No 1143192 Invacare® Adjustable ASBA Seats...
-
Page 34: Using The Cmpj+ Joystick
Select the desired operation using the joystick or an equivalent respectively. switch. While operating the powered seating system, the selected icon will display on the screen along with text indicating the current operation (Detail “C”). Invacare® Adjustable ASBA Seats Part No 1143192... - Page 35 DETAIL “C” - EXAMPLE SCREEN DURING POWERED SEATING OPERATION Joystick Speed Control Knob Icon Icon Text Remote On/ Programmable Mono Off Input Port 1/2 or External To Controller Mode Switch Text FIGURE 3 Using the CMPJ+ Joystick Part No 1143192 Invacare® Adjustable ASBA Seats...
-
Page 36: Programmable Mono Ports 1 And 2 With External Mode Switch
(normally open momentary switch with mono plug). To use the remote On/Off feature, the Drive Select/On/Off switch must be in the On position. Each activation of the ability switch will alternately turn the joystick On or Off. Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 37: Mode Switch
*In these modes, Standby Select allows the reset switch to be bypassed for users unable to activate the switch. Memory Card Slot The memory card slot is used with the basic or professional memory card for saving or reading wheelchair parameters. Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 38: About Front Riggings
To remove the footrest, push the footrest release lever inward, rotate footrest outward. FIGURE 4 Installing/Removing Footrests - Ph904A, Phal4A, 70° and Adjust footrest height, if desired. Refer to Footrest Height pw93 Adjustment on page 51. Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 39: Taper
Raising - Pull back on the release lever and raise front rigging Lever to the desired height. • Lowering - Support front rigging with one hand away from the release lever. Push release lever downward with other hand. FIGURE 6 Raising/Lowering Elevating Front Riggings Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 40: Installing/Removing Elevating Legrests
(facing the front of the wheelchair) and swing the legrest to the Bolt/Nut outside of the wheelchair. Lift UP on the legrest and remove from the wheelchair. Repeat STEPS 1- 2 for opposite side of wheelchair. FIGURE 7 Installing/Removing Elevating Legrests Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 41: Raising/Lowering Elevating Legrests And/Or Adjusting Calfpads
UP and down ramps. Refer to Raising/Lowering Elevating Legrests on page 41. Turn the calfpad towards the inside of the wheelchair. FIGURE 8 Raising/Lowering Elevating Legrests and/or Adjusting Calfpads Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 42: Removing/Installing The Manual Center Mount Footrest
Reinstall the rigging pivot pin to secure the center mount footrest to the mounting bracket of the seat frame. Rigging Pivot Seat Frame Mounting Bracket Center Mount Footrest FIGURE 9 Removing/Installing the Manual Center Mount Footrest Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 43: Installing/Removing The Power Elevating Legrests
The footplate will be on the INSIDE of the wheelchair when locked in place. Repeat STEPS 1-3 for the opposite legrest. Connect power legrest connector to jumper cable (Detail “B” of FIGURE 10). Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 44: Removing The Power Elevating Legrests
Lift up on powered legrest and remove from wheelchair. Repeat STEPS 1-3 for opposite power legrest. DETAIL “A” DETAIL “B” Calf Pad Mounting Pin Mounting Hole Jumper Cable Footplate Power Legrest Legrest Release Connector Handle FIGURE 10 Installing/Removing the Power Elevating Legrests Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 45: Installing/Removing Flip Back Armrests
Pull up on the flip back armrest and remove the armrest from the arm sockets. Rear Arm Seat Frame Repeat STEPS 1-3 for the opposite flip back armrest, if necessary. Socket Quick-Release Pin Front Arm Socket FIGURE 11 Installing/Removing Footrests Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 46: Adjusting Flip Back Armrests
Lock flip back armrest by pushing height adjustment lever into the Lift up on flip back armrest to make sure the armrest is locked in down (vertical) position. place. Repeat STEPS 1-4 for opposite flip back armrest, if necessary. Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 47: Using Non-Locking Cantilever Arms
Pull the end of the cantilever arm down to lower the cantilever arm. Pull the end of the cantilever arm up to move it out of the way. Cantilever Arm FIGURE 13 Using Non-Locking Cantilever Arms Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 48: Operating The Manual Recliner Option
When the back reaches the desired angle, slowly let go of the handles of the recliner cable assemblies. To return the back to the full upright position, reverse the above steps keeping in mind proper body mechanics. FIGURE 14 Operating the Manual Recliner Option Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 49: Operating The Manual Tilt Option (Tdx Spree Only)
A pinch point may occur when returning the tilted seat to the full upright position. Make sure the hands and body of the occupant, attendants and bystanders are clear of all pinch points before returning the tilted seat to the full upright position. Part No 1143192 Invacare® Adjustable ASBA Seats... - Page 50 When the seat reaches the desired angle, slowly let go of the two release levers to engage the manual tilt system. Stroller Seat Lock (Left) Wheelchair Handle Release Lever Base FIGURE 15 Operating the Manual Tilt Option (TDX Spree Only) Invacare® Adjustable ASBA Seats Part No 1143192...
-
Page 51: Adjustment
Securely tighten the lug bolt and locknut that secure the lower footrest to the footrest support. Repeat STEPS 1-3 for the opposite side of the wheelchair footrest, if necessary. FIGURE 1 Footrest Height Adjustment Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 52: And Pw93
Hex Bolt Washer necessary. Reinstall the footrest(s) onto the wheelchair. Refer to Installing/ Lower Removing Footrests on page 38. Footrest Reinstall any accessory onto the footrest(s). FIGURE 2 Footrest Height Adjustment - 70° and PW93 Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 53: Taper
Footrest Reinstall the footrest(s) onto the wheelchair. Refer to Installing/ Removing Footrests on page 38. FIGURE 3 Footrest Height Adjustment - 70° Taper Reinstall any accessory onto the footrest(s). Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 54: Adjusting Adjustable Angle Flip-Up Footplates
If desired depth is still not obtained, rotate the half clamp on the footplate hinge 180°. Washer Retighten the two flat screws, washers and locknuts. Locknut Nylon Adjustment Screw Half Clamp Footplate Hinge FIGURE 4 Adjusting Adjustable Angle Flip-Up Footplates Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 55: Angle Adjustment
Footplate footplate (FIGURE 4). Slowly turn nylon adjustment screw in or out until footplate is perpendicular to the footrest assembly or the desired inversion or eversion is obtained (FIGURE 6). FIGURE 6 Perpendicular and/or Inversion/Eversion Adjustment Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 56: Adjusting The Height Of The Manual Center Mount Footrest
Securely tighten. Extension Housing Button Head Repeat STEPS 1-3 for the other extension tube. Cleat Extension Tube Mounting Holes Mounting Screws Extension FIGURE 7 Adjusting the Height of the Manual Center Mount Footrest Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 57: Adjusting The Angle Of The Manual Center Mount Footrest
Footrest Disengage the release lever (not shown) to lock the center mount footrest in the new position. FIGURE 8 Adjusting the Angle of the Manual Center Mount Footrest Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 58: Adjusting The Footplate Angle
Screw the adjustment screw in or out until the desired angle is achieved. Mount Footrest Repeat STEPS 1 and 2 for the other footplate. Footplate (shown away from Extension Tube) Adjustment Screw FIGURE 9 Adjusting the Footplate Angle Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 59: Adjusting The Tension Of The Flip Up Footplate
To adjust the arm angle up, turn the adjustment screw counterclockwise. Arm Tube Repeat STEP 1 to adjust the other cantilever arm (as necessary). Adjustment Screw FIGURE 11 Adjusting the Angle of the Cantilever Arm Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 60: Adjusting The Back Angle
Torque the locknuts to 13 ft-lbs. DETAIL “A” - CANE Back Cane BRACKET MOUNTING HOLES Locknut 85° 95° Cane Bracket 90° 105° Washer Upper Hex 100° Screw Lower Hex Screw FIGURE 12 Adjusting the Back Angle Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 61: Adjusting The Manual Tilt Cable Assembly
Rotate the spreader bar either: Spreader Bar • Counterclockwise (away from back upholstery) to loosen Back back/headrest upholstery. Upholstery • Clockwise (towards back upholstery) to tighten back/headrest upholstery. FIGURE 14 Adjusting Back or Headrest Upholstery Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 62: Setup/Maintenance
Check that cables are routed and secured properly to ensure that cables DO NOT become entangled and damaged during normal operation of seating system. Ensure proper operation of powered functions (Example: seating and legrests). Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 63: User/Attendant Inspection Checklists
Inspect/Adjust Monthly Clean upholstery and armrests. Inspect seat positioning strap for any signs of wear. Ensure buckle latches. Verify hardware that attaches strap to frame is secure and undamaged. Replace if necessary. Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 64: Inspect/Adjust Periodically
After ANY adjustments, repair or service and before use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. CAUTION As with any vehicle, the wheels and tires should be checked periodically for cracks and wear, and should be replaced. Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 65: Six Month Inspection
Check power center mount front riggings for worn/frayed straps and/or loose fasteners. If found, replace these items. Powered Seating Systems - Make sure all electrical connections are secure. Powered Seating Systems - Make sure drive lock-out operates properly. Check limit switch position. Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 66: Replacing Heel Loops
Reverse STEPS 1-6 to reassemble. Heel Loop Lower When securing heel loop to lower footrest, Footrest tighten the phillips screw and locknut until the spacer is secure. Locknut FIGURE 1 Replacing Heel Loops Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 67: Adjusting/Replacing Telescoping Front Rigging Support
Secure the telescoping front tube to the side rail at the desired depth with the existing two cap screws, spacers and threaded blocks. Repeat STEPS 1 to 3 on the opposite side, if desired. Side Rail Spacers Cap Screws Side Rail Threaded Blocks Telescoping Front Tube Cap Screws Spacers FIGURE 2 Adjusting/Replacing Telescoping Front Rigging Support Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 68: Installing Adjustable Angle Flip-Up Footplate Hinge
If the footplate's motion is too loose, tighten mounting screw and locknut approximately ¼-turn clockwise. Adjust footplate. Refer to Installing Adjustable Angle Flip-up Footplates on page 69. Footplate Mounting Screw Hinge Locknut Washers Footrest Support Spacer FIGURE 3 Installing Adjustable Angle Flip-up Footplate Hinge Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 69: Installing Adjustable Angle Flip-Up Footplates
Adjust the footplates to the necessary angle and depth for the user. Refer to Adjusting Adjustable Angle Flip-Up Footplates on page 54. Footplate Footplate Hinge Half Clamp Washer Locknut Nylon Adjustment Screw Half Clamp Footplate Hinge FIGURE 4 Installing Adjustable Angle Flip-up Footplates Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 70: Composite/Articulating Footplate Heel Loop Replacement
Reverse steps in Disassembly to assemble. Mounting Screw When securing heel loop to the footrest assembly, tighten mounting screw until the spacer is secure. Heel Loop Articulating Footplate FIGURE 5 Composite/Articulating Footplate Heel Loop Replacement Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 71: Repositioning Joystick
Turn the adjustment lock lever to secure the joystick mounting tube into the mounting bracket. Mounting Bracket Mounting Bracket Hex Mounting (Threaded Screws Plate) Arm Tube Joystick Adjustment Lock Washers Mounting Lever Tube Joystick not shown. FIGURE 6 Repositioning Joystick Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 72: Disconnecting/Connecting The Joysticks
Lightly push to engage the joystick connector and the controller FIGURE 7 Disconnecting/Connecting the Joysticks - SPJ+ Joysticks connector. Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 73: Cmpj+ Joysticks
Push the latch in to secure the network connectors and caps. If necessary secure excess cable using tie-wraps. Controller Cable Gasket Bottom Connector Gasket FIGURE 8 Disconnecting/Connecting the Joysticks - CMPJ+ Joysticks Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 74: Replacing Seat Positioning Strap
75 in-lbs. Reinstall the seat cushion onto the seat pan. Seat Positioning Strap Halves Quick-Release Pin Tab FIGURE 9 Replacing Seat Positioning Strap - Wheelchairs without TRRO Option Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 75: Removing/Installing/Adjusting Headrest
Tighten the thumb screw that secures the headrest to the headrest mounting bracket. Tighten the set screw on the headrest stop. FIGURE 10 Removing/Installing/Adjusting Headrest If necessary, adjust the depth or direction of the headrest. Refer to Adjusting Headrest Depth/Direction on page 76. Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 76: Adjusting Headrest Depth/Direction
If necessary, adjust the height, depth or direction of the headrest. Refer to Adjusting Headrest Height or Adjusting Headrest Depth/Direction on page 76. Headrest Mounting Bracket One style of headrest shown for clarity. Both styles of headrest attach the same way. Socket Screw Headrest FIGURE 11 Replacing Headrest Invacare® Adjustable ASBA Seats Part No 1143192... -
Page 77: Replacing Back Or Headrest Upholstery
Install the six mounting screws that secure the headrest upholstery to the headrest extensions. Adjust the headrest upholstery to the desired tautness. Refer to FIGURE 12 Replacing Headrest Upholstery Adjusting Back or Headrest Upholstery on page 61. Part No 1143192 Invacare® Adjustable ASBA Seats... -
Page 78: Removing/Installing The Manual Tilt Release Lever From The Stroller Handle
Adjust the tilt release cable, if necessary. Refer to Adjusting the Manual Tilt Cable Assembly on page 61. Tilt Release Lever Tie-Wrap FIGURE 13 Removing/Installing the Manual Tilt Release Lever from the Stroller Handle Invacare® Adjustable ASBA Seats Part No 1143192... - Page 79 7 SETUP/MAINTENANCE Notes Invacare® Adjustable ASBA Seats Part No 1143192...
