T
Use of 8-, 16-, 32-, 64-, or 128-MB DIMMs installed in
any of the three sockets regardless of size; therefore,
dozens of combinations are possible. See the examples
of DIMM combinations in the following table.

Sample Memory Configurations

BANK 0 BANK 1
1Mx64 (8 MB) Empty (0 MB)
Empty (0 MB) 1Mx64 (8 MB)
1Mx64 (8 MB) 1Mx64 (8 MB)
2Mx64 (16 MB) 2Mx64 (16 MB)
2Mx64 (16 MB) 4Mx64 (32 MB)
4Mx64 (32 MB) 4Mx64 (32 MB)
8Mx64 (64 MB) 1Mx64 (8 MB)
2Mx64 (16 MB) 8Mx64 (64 MB)
4Mx64 (32 MB) 8Mx64 (64 MB)
2Mx64 (16 MB) 16Mx64 (128 MB)
16Mx64 (128 MB) 2Mx64 (16 MB)
16Mx64 (128 MB) 4Mx64 (32 MB)
16Mx64 (128 MB) 8Mx64 (64 MB)
16Mx64 (128 MB) 16Mx64 (128 MB)
TOTAL RAM
8 MB (min.
memory)
8 MB (min.
memory)
16 MB
32 MB
48 MB
64 MB
72 MB
80 MB
96 MB
144 MB
144 MB
160 MB
192 MB
256 MB
System Specifications B-3
