Running The Printer Set-Up Utility - NEC SuperScript 750C User Manual

6. Click on "Have Disk...". Insert the driver diskette/CD in
the appropriate drive of your PC. then follow the
instructions which appear on your PC screen.
7. At the end of the installation, you will be asked to
remove the diskette and restart Windows®.
The printing clarity and definition of photographs and high
resolution or fine pattern images require special paper; the
NEC-recommended Photo and Coated papers guarantee
optimum results.
For the use of these types of papers, refer to the
instructions contained in the paper packaging and the
section entitled Paper in the User's Manual.
The Photo Kit driver helps you to select the printing
parameters that give the best possible quality.
The driver's ON LINE Help contains many suggestions and
indications and a section of Problems and Solutions.
30

Running the Printer Set-Up Utility

This program runs under DOS. It should be used if the
feature you require cannot be selected through the driver
you have installed and you wish to modify your resident
printer parameters or if you wish to control the print head
alignment.
Use a good quality interface cable for your computer-
printer connection, to ensure correct communication
(ask your retailer for details).
G
Note for Windows® 95 users
If you have Windows® 95 installed on your PC, BEFORE
running the setup utility, you must disable the DOS spooler,
as follows:
1. Open the Printers folder, select your printer then the
Properties tab.
2. In the Details property sheet, click Port Settings.
3. A window entitled Configure LPT ports opens, with the
option Spool MS-DOS print jobs selected.
4. Click the box, to disactivate the option. This will enable
the DOS application to handle the port directly.
5. Click OK.
6. Click OK in the Details property sheet.
To re-enable the "Spool MS-DOS print jobs" feature, just
repeat the above procedure.
Using Software - Running the Printer Set-Up Utility
