GRAPHIC PRINTING (continued)
ESC * r n Q 27 42 114 n 81
ESC * r 0 Q 27 42 114 48 81
ESC * r 1 Q 27 42 114 49 81
ESC * r 2 Q 27 42 114 50 81
ESC * r 9 Q 27 42 114 57 81
ESC * r n A 27 42 114 n 65
ESC * b n W.. 27 42 98 n 87 ..
ESC * b n X 27 42 98 n 88
ESC * b n Y 27 42 98 n 89
ESC * r B 27 42 114 66
ESC * r C 27 42 114 67
ESC * g n W 27 42 103 n 87
ESC * p n N 27 42 112 n 78
ESC * p 0 N 27 42 112 48 78
ESC * p 1 N 27 42 112 49 78
ESC * p 2 N 27 42 112 50 78
ESC * p 3 N 27 42 112 51 78
ESC * o n Q 27 42 111 n 81
ESC * o 0 Q 27 42 111 48 81
ESC * o 1 Q 27 42 111 49 81
ESC * o 2 Q 27 42 111 50 81
B-8
1B 2A 72 n 51
Graphic Printing Quality
1B 2A 72 30 51 Default value (LQ)
1B 2A 72 31 51 NLQ
1B 2A 72 32 51 Letter Quality
1B 2A 72 39 51 Draft
1B 2A 72 n 41
Start Graphic Printing
( n = 0, start at left margin; n = 1, start at current cursor position)
1B 2A 62 n 57 .. Send Data for Graphic Printing (n is the data for one pixel raster row)
1B 2A 62 n 58
Horizontal (X) Offset (n is a number of blank dots - a multiple of eight -
inserted, starting from the left hand margin, at the beginning of the
raster row; one dot = 1/300 in)
1B 2A 62 n 59 Vertical (Y) Offset (n is a number of blank dots - a multiple of eight -
inserted before the raster row, starting from the top margin; one dot =
1/300 in)
1B 2A 72 42 End Graphic Printing
1B 2A 72 43 End Graphic Printing
1B 2A 67 n 57 Definition of graphic planes
1B 2A 70 n 4E Graphic Printing Direction
1B 2A 70 30 4E Default
1B 2A 70 31 4E Bidirectional
1B 2A 70 32 4E Left to right
1B 2A 70 33 4E Right to left
1B 2A 6F n 51 Shingling
1B 2A 6F 30 51 No shingling
1B 2A 6F 31 51 50% shingling (2 passes)
1B 2A 6F 32 51 25% shingling (4 passes)
Command Code Summary
