User Interface

This section describes the user interface of your printer, i.e.
those parts and features that you use and/or refer to during
the day-to-day use of the printer. The user interface
comprises the Printer Monitor which is loaded in your PC
when you install your printing system, the printer operator
panel and the templates embossed on the printer casing.

Printer Monitor

The Printer Monitor is an on-screen aid containing a series
of functions which help you during daily use of the printer. It
is displayed by clicking on the specific icon.
The Printer Monitor allows you to:
view the printer operating status during a print job. It
indicates the proportion of the document printed and
eventual error messages (Status),
perform printer care functions, to maintain optimum
working conditions (Printer Care):
– Align : print head alignment (checking accuracy of
bi-directional printing),
– Clean : print head cleaning,
– Demo : printing of the "demo" page,
– Test : printing of the printer test page.
User Interface - Printer Monitor
Checking print accuracy (Align)
Whenever you insert a new print head, you should
check the accuracy of bi-directional printing, to
guarantee optimum printing quality. The Printer Monitor in
your printing system makes this operation extremely easy:
Make sure that your printer and PC are powered, your
printing system is installed, both print heads are
inserted and paper is loaded.
1. Click the Printer Monitor icon.
2. Click the Printer Care tab.
3. Click the Align button, then follow the instructions
displayed.
Cleaning the print heads (Clean)
If you notice a deterioration in the print quality, before
changing either/both print heads, run the "Clean" function.
1. Click the Printer Monitor icon (if necessary).
2. Click the Printer Care tab.
3. Click the Clean button, then follow the instructions
displayed.
