3. Activate the Control Panel in the Main window, clicking
twice with your mouse indicator on the corresponding
icon.
4. Select the Printers icon, in the same way.
5. If the Installed Printers box is empty, click on Install..
6. If the Installed Printers box already contains one or
more driver names, click on Add>> , select Install
Unlisted or Updated Printer in the List of Printers and
then click on Install... .
7. Check that the Install Driver window already indicates
the drive (usually A) in which you have inserted the
driver diskette, otherwise, click on the drive name and
change it, using your PC keyboard; click on OK.
8. The Add Unlisted or Updated Printer window contains
the list of drivers present on the diskette. Select the
driver with your printer name and click on OK.
9. Your driver is now installed and your printer name
appears in the List of Printers.
10. With your printer name highlighted, click on the Set as
Default Printer button, so that your printer will be active
in all your Windows® applications.
11. Check your printer connection by clicking on the
Connect.. button.
By default, your printer will be connected on the LPT1
port which corresponds to the hardware connection of a
parallel interface cable.
12. Click on the Close button of the Printers dialogue box.
Quick Start
G
Windows® 95
The Microsoft Windows® 95 operating system allows
automatic installation of peripherals through the
"Plug & Play" feature, a bi-directional communication and
hardware recognition procedure.
1. Make sure that both printer and PC are powered.
The printer must NOT be in error mode, i.e. the
indicator lights must not be flashing.
2. Activate Microsoft Windows® 95. If already started,
execute the "Shut down" command and restart the
computer.
3. A window opens, indicating that a new peripheral has
been detected (New Hardware found and the printer
name).
The same window shows the Driver from disk
provided by hardware manufacturer option already
highlighted. Click the OK button.
4. With the Install from Disk window displayed, insert the
printer driver diskette in the drive selected, specify this
drive if requested and click OK.
5. The Add Printer Wizard window is displayed.
If there are no other printer drivers already installed on
your system, your printer will be installed as the Default
printer.
If other printer drivers are already installed, and you
wish to install the current one as the default printer, click
Yes and then the Finish button.
The installation of the driver files will start.
7
