Graphic Printing - NEC SuperScript 750C User Manual

Horizontal Positioning of Cursor
ESC & a n C 27 38 97 n 67
ESC & a + n C 27 38 97 43 n 67
ESC & a - n C 27 38 97 45 n 67
ESC * p n X 27 42 112 n 88
ESC * p + n X 27 42 112 43 n 88
ESC * p - n X 27 42 112 45 n 88
ESC & a n H 27 38 97 n 72
ESC & a + n H 27 38 97 43 n 72
ESC & a - n H 27 38 97 45 n 72
ESC & k n H 27 38 107 n 72

Graphic Printing

ESC * t n R 27 42 116 n 82
ESC * t 75 R 27 42 116 55 53 82
ESC * t 100 R 27 42 116 49 48 48 82
ESC * t 150 R 27 42 116 49 53 48 82
ESC * t 300 R 27 42 116 51 48 48 82
ESC * r n S 27 42 114 n 83
ESC * b 0 M 27 42 98 48 77
ESC * b 1 M 27 42 98 49 77
ESC * b 2 M 27 42 98 50 77
ESC * b 3 M 27 42 98 51 77
ESC * b 9 M 27 42 98 57 77
Command Code Summary
1B 26 61 n 43 Positioning first print position in column "n" (the horizontal movement is
calculated from the left margin; the number of columns per line depends
on the print pitch)
1B 26 61 2B n 43 Positioning "n" columns to the right
1B 26 61 2D n 43 Positioning "n" columns to the left
1B 2A 70 n 58
Positioning first print position on dot "n" (the dot positions are numbered
from the leftmost print position; one dot=1/300 in)
1B 2A 70 2B n 58 Positioning "n" dots to the right
1B 2A 70 2D n 58 Positioning "n" dots to the left
1B 26 61 n 48 Positioning first print position on decipoint "n" (the decipoint positions
are numbered from the leftmost print position; one decipoint = 1/720 in)
1B 26 61 2B n 48 Positioning "n" decipoints to the right
1B 26 61 2D n 48
Positioning "n" decipoints to the left
1B 26 6B n 48 Horizontal Motion Index (HMI) n/120 in
1B 2A 74 n 52 Graphic Resolution
1B 2A 74 37 35 52 75 dpi print density
1B 2A 74 31 30 30 52 100 dpi print density
1B 2A 74 31 35 30 52 150 dpi print density
300 dpi print density
1B 2A 74 33 30 30 52
1B 2A 72 n 53 Graphic Printing Width ( n depends on the width of the image created
and is limited by the page width)
1B 2A 62 30 4D Normal Graphic Printing
1B 2A 62 31 4D Compacted Mode 1
1B 2A 62 32 4D Compacted Mode 2
1B 2A 62 33 4D Compacted Mode 3
1B 2A 62 39 4D Compacted Mode 9
(continued)
B-7
