2. Plug the printer power cable into a wall socket.
The socket outlet shall be installed near the equipment
and shall be easily accessible.
Make sure the electrical power supplied has the voltage
indicated on the electrical data plate on the base of the
printer.
If the electrical data plate indicates a different voltage, call
your local retailer immediately. DO NOT, UNDER ANY
CIRCUMSTANCES, CONNECT THE PRINTER TO THE
ELECTRICAL POWER SUPPLY.
Make sure that the plug on the power cable of the printer
is of the type accepted by the wall socket you intend to
use; if it is not, call your local retailer.
Do NOT attempt to change the plug yourself.
The manufacturer declines all responsibility for accidents
to persons or damage to the printer arising from the
non-observance of this warning.
To your computer
See figures 3a to 5a on page II.
The interface cable is not supplied with the printer;
consult your systems engineer or retailer for advice on
the type of cable you require.
Make sure that your computer/host system is switched
off and that the printer is not powered.
2
1. The interface socket cover, which covers the parallel
interface cable, is in the accessories kit delivered in the
printer packaging.
2. Plug the interface cable connector into the socket and, if
necessary, close the spring clips on it.
3. Mount the socket cover over the interface connector.
4. Connect the other end of the interface cable to the
appropriate interface connector socket (port) on your
computer/host system.
5. Press the POWER key on the printer operator panel and
switch on your computer.
The printer will take a few moments to execute a series
of internal checks. It will be in ON LINE condition (both
light indicators will be lit).
After approximately 2 minutes of inactivity, the
printer will go into "standby" mode. In standby
mode, the print head carriage returns to and remains
in its rest position at the right hand end of its path
and there is a reduction in the power consumption
(the light indicators on the operator panel remain lit).
To reactivate the printer, just send a file to be
printed or start any other printer operation.
