Color Printing

ESC * b n S 27 42 98 n 83
ESC * b n V 27 42 98 n 86
ESC * r n U 27 42 114 n 85
ESC * r -3 U 27 42 114 45 51 85
ESC * r 0 U 27 42 114 48 85
ESC * r 1 U 27 42 114 49 85
ESC * r 3 U 27 42 114 51 85
ESC * o n D 27 42 111 n 68
ESC * o 1 D 27 42 111 49 68
ESC * o 2 D 27 42 111 50 68
ESC * o 3 D 27 42 111 51 68
B-10
1B 2A 65 n 53 Seed row select source plane to compacted modes 3 and 9 (graphics)
1B 2A 65 n 56 Data Transfer in Planes
(n = number of bytes of binary data to be sent to the printer.)
1B 2A 72 n 55
Selects Monochrome/Color Printing
1B 2A 72 2D 33 55 Selects color palette: cyan, magenta, yellow
1B 2A 72 30 55 Selects monochrome printing
1B 2A 72 31 55 Selects monochrome printing
1B 2A 72 33 55 Selects color palette: red, green, blue
1B 2A 6F n 44 Image Depletion
1B 2A 6F 31 44 No depletion
1B 2A 6F 32 44 25% depletion
1B 2A 6F 33 44 50% depletion
Command Code Summary
