Dimensions

The following table indicates the document formats you can
use in your printer:
A4 210 x 297 mm
8.26 x 11.7 in
A5 148.5 x 210 mm
(vertical) 5.85 x 8.26 in
Letter 8.5 x 11 in
215.9 x 279.4 mm
Legal 8.5 x 14 in
215.9 x 355.6 mm
Executive 7.25 x 10.5 in
184.2 x 266.7 mm
#1 4 x 6 in
#2 5 x 8 in
24
COM-10 4.125 x 9.5 in
104.7 x 241.3 mm
DL 110 x 220 mm
4.33 x 8.66 mm
C5 162 x 228 mm
6.37 x 9 in
C6 114 x 162 mm
4.4 x 6.27 in
B6 125 x 176 mm
4.92 x 6.92 in
A6 105 x 148.5 mm

Document Insertion

You can insert all document formats both in packs through
the ASF or manually, one at a time, through the manual
feeder. A single document in the manual feeder will have
insertion priority over the document(s) in the ASF.
The documents, including small formats such as A5, note
cards and envelopes, should always be inserted with their
shorter side as the leading edge.
For document insertion in the ASF, see figures 1h to 6h on
page IX and the description in the Quick Start.
Envelopes, glossy, coated, transparencies and T-Shirt
transfers should be inserted with their printing side face up
and envelopes must have the sealing flap underneath.
When using envelopes, remember to select a landscape
font for printing. When using as type of special printing
media, always select the appropriate printing feature (Photo,
Art, etc.) When using T-Shirt transfers, remember to select
the reverse printing feature ("Mirror").
G
in the ASF
The paper pack must not exceed 12 mm (0.45 in) for
standard plain paper and envelopes, (approximately
120 single sheets or 25 envelopes) and 6 mm (0.23 in)
for all other types of printing media.
If you use a narrow document format (less 165 mm (6.5
in) wide) or any type of envelope, you must use the
intermediate right hand margin guide , opening it
outwards ( see figures 1j and 2j on page X ) before
inserting the document to be printed.
