MakerBot Replicator 2x User Manual page 29

LOADiNg mAKErBOT ABS FiLAmENT
Stop Extrusion
7
Watch the right extruder nozzle. After a
few moments, you should see a thin string
of the MakerBot ABS Filament that you
loaded come out of the nozzle. Press the
M button to stop extrusion.
NOTE: Don't be surprised if the filament that
initially comes out of the nozzle is not the color you
expected. There's probably some filament inside
the extruder left over from our testing process at the
MakerBot factory. Wait until you see the color that
you loaded come out of the nozzle before you press
the M button.
Press the M to Continue
8
After the MakerBot ABS Filament is loaded into the right extruder, the LCD panel will
prompt you to load filament into the left extruder. Click through the message until your
MakerBot Replicator 2X asks you to press the M when you see plastic extruding.
Push the Filament into the Left Extruder
9
Take the end of the MakerBot ABS Filament
closest to the extruder and firmly push
it into the hole in the top of the extruder.
Ensure that the filament goes into the
center of the opening and doesn't get caught
at the edge of the opening.
Maintain pressure on the filament and continue
pushing it into the opening. After about five
seconds, you should begin to feel the motor
pulling in the filament. Maintain pressure for
another five seconds and then let go.
C STARTUP PROCESS: LEVELING, LOADING, TESTING
CONTINUED
29
