Network Commands

get network
set ipmode <static | dhcp>
set ipaddress <dotted decimal>
set subnet <dotted decimal>
set gateway <dotted decimal>
set http port <0-65535>
set telnet port <0-65535>
set heartbeat port <0-65535>
set dxp port <0-65535>
set dxp control <enable/disable>
set dxp query <enabled/disable>
set linkback <url>
set time server <dotted decimal>
set timeout <0-999>
V130108E
All set commands require a reboot before they take effect. These
commands are only available to the administrator.
This command will return all the network settings as
shown below:
Mode: Static
IP Addres: 192.168.1.190
Subnet: 255.255.255.0
Gateway: 192.168.1.1
HTTP Port: 80
Linkback URL: 192.168.1.190
Telnet Port: 23
Heartbeat Port: 9100
DxP Port: 9100
DxP Control: Enabled
DxP Query: Enabled
Timeout: 22
This command sets the IP Address setting mode. Static
mode locks the address as set, dhcp mode allows DHCP
server to assign address.
This command is used to set the iBoot-G2's ip address.
This command is used to set the iBoot-G2's subnet
mask.
This command is used to set the Gateway
This command sets the port that the iBoot-G2's web
server listens for incoming connections on. When set to
0 the web server is disabled.
This command sets the port that the iBoot-G2's Telnet
server listens for incoming connections on. When set to
0 the Telnet server is disabled
This command sets the port for the heartbeat protocol.
The heartbeat uses UDP and can be the same port
number as DxP, which is TCP
This command sets the port that the iBoot-G2's DxP
protocol service listens for incoming connections on.
When set to 0 the Protocol service is disabled.
Note: At least one of the above MUST NOT be 0. The
CLI will protect against all 3 from being set to 0.
This command allows the main and expansion ports to
be controlled using Dataprobe Exchange Protocol (DxP)
commands.
This command allows the status of the main and
expansion ports to be queried using DxP
This command sets the linkback URL displayed on the
logout page.
This command is used to set the IP Address of a
network time server.
This command sets the automatic network timeout in
minutes.
iBoot-G2+
192.168.1.254
255.255.255.0
192.168.1.1
80
23
9100
9100
Disabled
Enabled
192.168.1.254
69.90.182.55
2
Page 27
