Action: select from
None
Power On – Latch
Power On – Follow
Power Off – Latch
Power Off – Follow
Power Cycle
Times
Outlet: Select Main for the internal power outlet, or Exp1, Exp 2 for either of the two expansion ports.
7.9. Using Heartbeat Monitor
With Heartbeat operational, the main iBoot-G2+ page will display the current status of this feature. The status
will be OK to indicate that iBoot-G2+ is receiving heartbeats, or that the fail counter has not yet been
exceeded.
If the fail count has been exceeded, the status will change to Triggered. The Trigger Counter indicates the
number of times the Heartbeat feature has been triggered. A counter reset button is provided when logging in
with the System password.
7.10. Using the Heartbeat Program
The heartbeat program and instructions are available at
V130108E
Heartbeat not used
Upon triggering, iBoot-G2+ will power on and remain so until changed via the
web, ibootctl.exe or direct messaging.
Upon triggering, iBoot-G2+ will power on. When the heartbeat returns,
iBoot-G2+will power off.
Upon triggering, iBoot-G2+ will power off and remain so until changed via the
web, ibootctl.exe or direct messaging.
Upon triggering, iBoot-G2+ will power off. When the heartbeat response
returns, iBoot-G2+ will power on.
Upon triggering, iBoot-G2+ will cycle the power. If Power Cycle does not
result in the heartbeat being received, the iBoot-G2+ can cycle again. The
number of times the iBoot-G2+ will cycle is set by the Times setting. To
have the iBoot cycle power 3 times to get the system to respond again, set
the Times to 3.
iBoot-G2+
http://dataprobe.com/support/iboot.html
