D Technical Specifications

Environmental Specifications

Note: Your Adaptec Host Bus Adapter requires adequate airflow to operate reliably.
The recommended airflow is 200 LFM (linear feet per minute), minimum. Forced
airflow is required.
Ambient temperature with forced airflow
Relative humidity
Altitude
Note: Ambient temperature is measured 1" from the HBA processor.

DC Power Requirements

Bus Type
PCIe
PCIe

Current Requirements

Adaptec Model
Adaptec SAS HBA 70165H/70165He
Adaptec SAS HBA 7085H
Adaptec SAS HBA 71605H/71605He
Adaptec SAS HBA 7805H
Adaptec SAS HBA 6405H
Adaptec SAS HBA 6805H
Proprietary and Confidential to PMC-Sierra, Inc.
Document No.: CDP-00279-01-A Rev. A, Issue:
Serial Attached SCSI Host Bus Adapters Installation and User's Guide
Description
Ripple and noise
DC Voltage
Typical Current
0.17A @ 3.3 VDC; 1.25A @ 12.0 VDC
0.17A @ 3.3 VDC; 1.25A @ 12.0 VDC
0.17A @ 3.3 VDC; 1.25A @ 12.0 VDC
0.17A @ 3.3 VDC; 1.25A @ 12.0 VDC
0.09A @ 3.3 VDC; 0.7A @ 12.0 VDC
0.09A @ 3.3 VDC; 0.7A @ 12.0 VDC
0 °C to 55 ° C
10% to 90%, non-condensing
Up to 3,000 meters
Requirements
Adaptec SAS Adapter 7xxx5:
3.3V: 50 mV peak-to-peak (max)
12V: 120 mV peak-to-peak (max)
Adaptec SAS Adapter 6xx5:
3.3V : 5.5 mV peak-to-peak (max)
12V : 80mV peak-to-peak (max)
3.3V ± 9%, 12V ± 8%
