About the Adaptec SAS Adapter 7805H

The Adaptec SAS Adapter 7805H is a SAS Host Bus Adapter with these features:
Form Factor
Bus compatibility
PCIe bus width
Data transfer rate
Phys (Unified Serial Ports)
Connectors, internal
Maximum number of disk drives
Enclosure Support
Thermal Sensor
Encryption
Proprietary and Confidential to PMC-Sierra, Inc.
Document No.: CDP-00279-01-A Rev. A, Issue:
Serial Attached SCSI Host Bus Adapters Installation and User's Guide
2 internal
mini-SAS HD
connectors
Drive Activity
LED connector
PCIe x8 connector
Low-profile MD2 SFF card size
PCIe Gen3
x8
6 Gb/s per port
16
4 mini-SAS HD x4 (SFF-8643)
16 direct-attached (or up to 128 with expanders)
SES2 and SGPIO (Serial General Purpose Input/Output)
Processor temperature
No
HDA Mode (flash)
connector
18
