About the Adaptec SAS Adapter 6805H

The Adaptec SAS Adapter 6805H is a SAS Host Bus Adapter with these features:
Form Factor
Bus compatibility
PCIe bus width
Data transfer rate
Phys (Unified Serial Ports)
Connectors, internal
Maximum number of disk drives
Enclosure Support
Thermal Sensor
Encryption
Proprietary and Confidential to PMC-Sierra, Inc.
Document No.: CDP-00279-01-A Rev. A, Issue:
Serial Attached SCSI Host Bus Adapters Installation and User's Guide
PCIe x4 connector
Low-profile MD2 SFF card size
PCIe Gen2
x4
6 Gb/s per port
8
2 mini-SAS x4 (SFF-8087)
8 direct-attached (or up to 128 with expanders)
SES2 and SGPIO (Serial General Purpose Input/Output)
No
No
2 internal
mini-SAS
connectors
CN1
CN0
20
