Adaptec SAS Adapter 7085H/7805H LED Connector Specification

2278400-R
2280800-R
• Adaptec SAS Adapter 7085/7805 Activity LED Header Connector: Molex 015-91-3040 or equivalent
• Activity LED Header Mating Cable Connector: 6 pin 2.54mm pitch connector, Molex/Amp equivalent
J4:
J4 Pin Number Signal
1 PHY_ACT0_LED
2 +3.3V
3 PHY_ACT1_LED
4 +3.3V
Proprietary and Confidential to PMC-Sierra, Inc.
Document No.: CDP-00279-01-A Rev. A, Issue:
Serial Attached SCSI Host Bus Adapters Installation and User's Guide
ASA-7085H SGL
ASA-7805H SGL
Description
LED Cathode
LED Anode
LED Cathode
LED Anode
Mating Cable
Pin Number
2
1
4
3
