B Adapter LED Connector Quick Reference
This section provides a quick reference for Adaptec HBA drive activity LED connectors.
Adaptec SAS Adapter 70165H/70165He/71605H/71605He LED Connector
Specification
2278500-R
2278200-R
2278300-R
2278100-R
• Adaptec SAS Adapter 70165/71605 Activity LED Header Connector: Molex 015-91-3086 or equivalent
• Activity LED Header Mating Cable Connector: 6 pin 2.54mm pitch connector, Molex/Amp equivalent
J4:
J4 Pin Number
1
2
3
4
5
6
7
8
Proprietary and Confidential to PMC-Sierra, Inc.
Document No.: CDP-00279-01-A Rev. A, Issue:
ASA-70165H SGL
ASA-70165He SGL
ASA-71605H SGL
ASA-71605He SGL
Signal
PHY_ACT0_LED
+3.3V
PHY_ACT1_LED
+3.3V
PHY_ACT2_LED
+3.3V
PHY_ACT3_LED
+3.3V
Serial Attached SCSI Host Bus Adapters Installation and User's Guide
Description
LED Cathode
LED Anode
LED Cathode
LED Anode
LED Cathode
LED Anode
LED Cathode
LED Anode
Mating Cable
Pin Number
2
1
4
3
6
5
8
7
