Rf Unit - Icom IC-T81E Service Manual

[LOGIC UNIT]
REF ORDER
NO. NO.
C307 4030013850 S.CERAMIC
C308 4030014500 S.CERAMIC
C309 4030009000 S.CERAMIC
C310 4030014220 S.CERAMIC
C311 4550005980 S.TANTALUM
C312 4030014220 S.CERAMIC
C313 4030006880 S.CERAMIC
C314 4030013850 S.CERAMIC
C315 4030013850 S.CERAMIC
C316 4550005980 S.TANTALUM
C317 4030008920 S.CERAMIC
C318 4030009820 S.CERAMIC
C319 4030013850 S.CERAMIC
C320 4030013850 S.CERAMIC
C321 4030013850 S.CERAMIC
C322 4030013850 S.CERAMIC
C323 4030013850 S.CERAMIC
C324 4030013850 S.CERAMIC
C325 4030013850 S.CERAMIC
C326 4030013850 S.CERAMIC
C328 4030013850 S.CERAMIC
C361 4030008920 S.CERAMIC
C362 4030013850 S.CERAMIC
C700 4030011600 S.CERAMIC
C701 4030014320 S.CERAMIC
C703 4030013850 S.CERAMIC
C706 4030009820 S.CERAMIC
C707 4030011600 S.CERAMIC
C708 4030011600 S.CERAMIC
C709 4550006680 S.TANTALUM
C712 4030014170 S.CERAMIC
C713 4030013850 S.CERAMIC
C714 4030011600 S.CERAMIC
C715 4030011600 S.CERAMIC
C716 4030011600 S.CERAMIC
C718 4030011600 S.CERAMIC
C719 4030011600 S.CERAMIC
C720 4030008920 S.CERAMIC
C733 4030013850 S.CERAMIC
C734 4030013850 S.CERAMIC
C735 4030011600 S.CERAMIC
C736 4030013850 S.CERAMIC
C737 4030009820 S.CERAMIC
C751 4030011600 S.CERAMIC
C752 4030014150 S.CERAMIC
C753 4030009820 S.CERAMIC
C754 4030011600 S.CERAMIC
C755 4030008920 S.CERAMIC
C756 4030009820 S.CERAMIC
C757 4030009000 S.CERAMIC
C758 4550005980 S.TANTALUM
C759 4030013850 S.CERAMIC
C901 4030013850 S.CERAMIC
C903 4030013850 S.CERAMIC
C904 4030013850 S.CERAMIC
C906 4030013850 S.CERAMIC
C907 4030013850 S.CERAMIC
C909 4030013850 S.CERAMIC
C910 4030013850 S.CERAMIC
C912 4030013850 S.CERAMIC
C913 4030013850 S.CERAMIC
C914 4030013850 S.CERAMIC
C917 4030013850 S.CERAMIC
C918 4030013850 S.CERAMIC
C919 4030011600 S.CERAMIC
C923 4030014180 S.CERAMIC
C926 4030013850 S.CERAMIC
C927 4030013850 S.CERAMIC
J1 6510019860 S.CONNECTOR AXK6S40645P
J3 6450002010 S.CONNECTOR HSJ1501-011010
J4 6450001680 CONNECTOR
DS1 5040002230 S.LED
DS3 5010000150 S.LED
DS4 5030001700 LCD
MC1 7700002310 MICROPHONE EM-140
DESCRIPTION
ECUE1E102KBQ
ECUE1H121JCQ
C2012 JB 1C 224K-T-A
ECUE1E471KBQ
TEMSVA 1A 475M-8L
ECUE1E471KBQ
C1608 JB 1H 472K-T-A
ECUE1E102KBQ
ECUE1E102KBQ
TEMSVA 1A 475M-8L
C1608 JB 1C 473K-T-A
C1005 JB 1C 103K-T-A
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
C1608 JB 1C 473K-T-A
ECUE1E102KBQ
C1608 JB 1C 104KT-N
ECUE1H181JCQ
ECUE1E102KBQ
C1005 JB 1C 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
ECST0JY156R
ECUE1H330JCQ
ECUE1E102KBQ
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 473K-T-A
ECUE1E102KBQ
ECUE1E102KBQ
C1608 JB 1C 104KT-N
ECUE1E102KBQ
C1005 JB 1C 103K-T-A
C1608 JB 1C 104KT-N
ECUE1H220JCQ
C1005 JB 1C 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 473K-T-A
C1005 JB 1C 103K-T-A
C2012 JB 1C 224K-T-A
TEMSVA 1A 475M-8L
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
C1608 JB 1C 104KT-N
ECUE1H470JCQ
ECUE1E102KBQ
ECUE1E102KBQ
HSJ1122-010010
CL-200YG-C-TS
LT1EP53A
LM-1782B
[LOGIC UNIT]
REF ORDER
NO. NO.
S7 2260002530 S.SWITCH
S401 2230000900 S.SWITCH
S402 2230000900 S.SWITCH
W1 9020720180 WIRE
EP1 0910051324 PCB
EP2 8930048950 LCD CONTACT SRCN-2135-SP-N-W

[RF UNIT]

REF ORDER
NO. NO.
IC2 1130007510 S.IC
IC3 1130007510 S.IC
IC6 1180001720 S.IC
IC51 1110003370 S.IC
IC501 1110003370 S.IC
IC601 1110004020 S.IC
IC801 1130007610 S.IC
IC802 1130009370 S.IC
IC901 1110004050 S.IC
Q1 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q2 1590001170 S.TRANSISTOR XP1501-(TX) AB
Q3 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q4 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q5 1590001140 S.TRANSISTOR UN9210 (TX)
Q6 1590002580 S.FET
Q9 1590001650 S.TRANSISTOR XP4601 (TX)
Q51 1530003650 S.TRANSISTOR 2SC5319 (TE85L)
Q53 1590001690 S.TRANSISTOR UN9115 (TX)
Q101 1530003560 S.TRANSISTOR 2SC5195-T1
Q131 1530003560 S.TRANSISTOR 2SC5195-T1
Q132 1530003660 S.TRANSISTER 2SC5454-T1 R54
Q133 1530002560 S.TRANSISTOR 2SC4403-3-TL
Q134 1530000371 S.TRANSISTOR 2SC3356 R25-T2B
Q135 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q136 1530000371 S.TRANSISTOR 2SC3356 R25-T2B
Q138 1590002640 S.FET
Q139 1590001690 S.TRANSISTOR UN9115 (TX)
Q140 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q201 1580000700 S.FET
Q202 1590001690 S.TRANSISTOR UN9115 (TX)
Q301 1580000690 S.FET
Q302 1590002380 S.TRANSISTOR XP1115 (TX)
Q341 1530003640 S.TRANSISTOR 2SC4215-O (T5RICOM)
Q342 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q343 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q401 1530003560 S.TRANSISTOR 2SC5195-T1
Q403 1590001690 S.TRANSISTOR UN9115 (TX)
Q501 1530003560 S.TRANSISTOR 2SC5195-T1
Q502 1590002380 S.TRANSISTOR XP1115 (TX)
Q503 1590001860 S.TRANSISTOR UN9215 (TX)
Q602 1590001980 S.TRANSISTOR XP4315 (TX)
Q701 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q721 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q803 1560000540 S.FET
Q804 1560000540 S.FET
Q805 1530003000 S.TRANSISTOR 2SC4117-BL (TE85R)
Q807 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q811 1560000540 S.FET
Q812 1530003000 S.TRANSISTOR 2SC4117-BL (TE85R)
Q813 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q816 1530002930 S.TRANSISTOR 2SC4228 (M) -T1 R45
Q817 1590001150 S.TRANSISTOR UN9211 (TX)
Q818 1590002560 S.TRANSISTOR XP1116 (TX)
Q819 1590002560 S.TRANSISTOR XP1116 (TX)
Q820 1590001850 S.TRANSISTOR UN9116 (TX)
Q821 1530002560 S.TRANSISTOR 2SC4403-3-TL
Q822 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q823 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q824 1530003560 S.TRANSISTOR 2SC5195-T1
Q825 1590001970 S.TRANSISTOR UN921E (TX)
6 - 3
DESCRIPTION
EVQ-WRR001
JPM1990-2013R
JPM1990-2013R
71/98/040/X98/X98
B 5136D
DESCRIPTION
BU4094BCFV-E1
BU4094BCFV-E1
S-81332HG-KC-T1
µPC2748T-E3
µPC2748T-E3
µPC2757T-E3
µPD3140GS-E1 (DS8)
TB31242FN (EL)
NJM3404AV-TE1
HAT1024R-EL
MXR9745RT1
3SK292 (TE85R)
3SK291 (TE85R)
2SK880-Y (TE85R)
2SK880-Y (TE85R)
2SK880-Y (TE85R)
S.=Surface mount
