Icom IC-T81E Service Manual page 28

[RF UNIT]
REF ORDER
NO. NO.
L143 6200006770 S.COIL
L201 6200008730 S.COIL
L202 6200008730 S.COIL
L205 6200008730 S.COIL
L206 6200008730 S.COIL
L301 6200007750 S.COIL
L302 6200007750 S.COIL
L303 6200007720 S.COIL
L304 6200007760 S.COIL
L305 6200007780 S.COIL
L306 6200007780 S.COIL
L341 6200004920 S.COIL
L342 6200007670 S.COIL
L343 6200008750 S.COIL
L344 6200006980 S.COIL
L345 6200007000 S.COIL
L346 6200006670 S.COIL
L347 6200006990 S.COIL
L348 6200007000 S.COIL
L401 6200007690 S.COIL
L402 6200007690 S.COIL
L403 6200005680 S.COIL
L404 6200005690 S.COIL
L501 6200005720 S.COIL
L502 6200005660 S.COIL
L503 6200005660 S.COIL
L504 6200005700 S.COIL
L505 6200005700 S.COIL
L507 6200005700 S.COIL
L701 6200002710 S.COIL
L721 6200005190 S.COIL
L723 6200004720 S.COIL
L724 6200003640 S.COIL
L725 6200003640 S.COIL
L726 6200005190 S.COIL
L801 6200003550 S.COIL
L802 6200003550 S.COIL
L804 6200003550 S.COIL
L806 6200005630 S.COIL
L807 6200003540 S.COIL
L808 6200006980 S.COIL
L809 6200005700 S.COIL
L810 6200005670 S.COIL
L811 6200005620 S.COIL
L905 6200008700 S.COIL
L906 6200003590 S.COIL
L907 6200003590 S.COIL
L908 6200008100 S.COIL
L909 6200005640 S.COIL
L910 6200005580 S.COIL
L911 6200005580 S.COIL
L912 6200008180 S.COIL
L913 6200008370 S.COIL
6200008200 S.COIL
L914 6200008080 S.COIL
L915 6200008080 S.COIL
L916 6200008210 S.COIL
L917 6200008190 S.COIL
L918 6200008400 S.COIL
L919 6200008300 S.COIL
L920 6200008360 S.COIL
L921 6200004480 S.COIL
L922 6200004480 S.COIL
L923 6200004480 S.COIL
L924 6200004480 S.COIL
L925 6200008080 S.COIL
L926 6200007770 S.COIL
L931 6200004480 S.COIL
L932 6200003640 S.COIL
L933 6200005580 S.COIL
R1 7030005040 S.RESISTOR
R2 7030005050 S.RESISTOR
R3 7030005040 S.RESISTOR
R4 7030005050 S.RESISTOR
R7 7030005090 S.RESISTOR
R8 7030000180 S.RESISTOR
R9 7030000180 S.RESISTOR
R10 7030005050 S.RESISTOR
R13 7510000910 S.THERMISTOR NTCCF2012 4AH 473KC-T
R14 7030005240 S.RESISTOR
DESCRIPTION
ELJRE 1N5Z-F
ELJND R10J 0.1U
ELJND R10J 0.1U
ELJND R10J 0.1U
ELJND R10J 0.1U
LQN21A 56NJ04
LQN21A 56NJ04
LQN21A 33NJ04
LQN21A 82NJ04
LQN21A R12J04
LQN21A R12J04
MLF1608A 2R2K-T
LQN21A 10NJ04
LQN1H R29J04
ELJRE R10G-F
ELJRE 82NG-F
ELJRE 68NG-F
ELJRE 56NG-F
ELJRE 82NG-F
LQN21A 18NJ04
LQN21A 18NJ04
ELJRE 15NG-F
ELJRE 18NG-F
ELJRE 33NG-F
ELJRE 10NG-F
ELJRE 10NG-F
ELJRE 22NG-F
ELJRE 22NG-F
ELJRE 22NG-F
ELJFC 1R8K-F
MLF1608D R56K-T
MLF1608D R10K-T
MLF1608K 100K-T
MLF1608K 100K-T
MLF1608D R56K-T
MLF1608A 4R7K-T
MLF1608A 4R7K-T
MLF1608A 4R7K-T
ELJRE 5N6Z-F
MLF1608D R22K-T
ELJRE R10G-F
ELJRE 22NG-F
ELJRE 12NG-F
ELJRE 4N7Z-F
0.30-0.9-6TR 17.5N
EXCCL3225U1
EXCCL3225U1
LQN1H R14J04
ELJRE 6N8Z-F
ELJRE 2N2Z-F
ELJRE 2N2Z-F
0.25-1.9-10TL 107N
0.40-1.3-2TL [USA-1] only
0.40-1.4-2TL [other]
LQN21A R22J04
LQN21A R22J04
0.45-1.5-5TL 23.2N
0.25-1.9-8TL 80N
0.35-1.6-6TL 36N
0.35-1.6-9TL 65N
0.25-1.9-13TL
MLF1608D R82K-T
MLF1608D R82K-T
MLF1608D R82K-T
MLF1608D R82K-T
LQN21A R22J04
LQN21A R10J04
MLF1608D R82K-T
MLF1608K 100K-T
ELJRE 2N2Z-F [EUR], [UK], [ITA]
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 104 X (100 kΩ)
MCR10EZHJ 22 Ω (220)
MCR10EZHJ 22 Ω (220)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 473 X (47 kΩ)
[RF UNIT]
REF ORDER
NO. NO.
R15 7030005220 S.RESISTOR
R16 7030005220 S.RESISTOR
R31 7030007300 S.RESISTOR
R32 7030007300 S.RESISTOR
R33 7030007300 S.RESISTOR
R51 7030005290 S.RESISTOR
R52 7030005040 S.RESISTOR
R53 7030005570 S.RESISTOR
R57 7030005120 S.RESISTOR
R58 7030007270 S.RESISTOR
R100 7030005090 S.RESISTOR
R103 7030005060 S.RESISTOR
R106 7030007280 S.RESISTOR
R110 7030005170 S.RESISTOR
R111 7030007280 S.RESISTOR
R112 7030005170 S.RESISTOR
R113 7030005040 S.RESISTOR
R121 7030008410 S.RESISTOR
R122 7030004980 S.RESISTOR
R123 7030008410 S.RESISTOR
R124 7030008410 S.RESISTOR
R125 7030007300 S.RESISTOR
R126 7030007250 S.RESISTOR
R128 7030005040 S.RESISTOR
R131 7030004970 S.RESISTOR
R132 7030009160 S.RESISTOR
R133 7030007250 S.RESISTOR
R134 7030005530 S.RESISTOR
R135 7030004970 S.RESISTOR
R138 7030007270 S.RESISTOR
R139 7030007300 S.RESISTOR
R140 7030004970 S.RESISTOR
R141 7030004970 S.RESISTOR
R142 7030008410 S.RESISTOR
R143 7030009140 S.RESISTOR
R144 7030008410 S.RESISTOR
R145 7030007270 S.RESISTOR
R146 7030009290 S.RESISTOR
R147 7030004970 S.RESISTOR
R149 7030008410 S.RESISTOR
R150 7030009140 S.RESISTOR
R152 7030008410 S.RESISTOR
R156 7030004980 S.RESISTOR
R157 7030008410 S.RESISTOR
R158 7030008410 S.RESISTOR
R159 7030005080 S.RESISTOR
R160 7030005090 S.RESISTOR
R161 7030008410 S.RESISTOR
R163 7030008410 S.RESISTOR
R165 7030007300 S.RESISTOR
R166 7030007300 S.RESISTOR
R201 7030005080 S.RESISTOR
R202 7030005090 S.RESISTOR
R203 7030005310 S.RESISTOR
R204 7030005220 S.RESISTOR
R205 7030005160 S.RESISTOR
R206 7030004980 S.RESISTOR
R207 7030005050 S.RESISTOR
R208 7030004980 S.RESISTOR
R209 7030005090 S.RESISTOR
R210 7030005040 S.RESISTOR
R301 7030005040 S.RESISTOR
R302 7030005120 S.RESISTOR
R303 7030005040 S.RESISTOR
R304 7030005090 S.RESISTOR
R306 7030005090 S.RESISTOR
R307 7030005310 S.RESISTOR
R308 7030005530 S.RESISTOR
R309 7030004970 S.RESISTOR
R310 7030005050 S.RESISTOR
R311 7030005090 S.RESISTOR
R312 7030005090 S.RESISTOR
R316 7030005040 S.RESISTOR
R341 7030006610 S.RESISTOR
R342 7030009140 S.RESISTOR
R343 7030004970 S.RESISTOR
R344 7030005720 S.RESISTOR
R345 7030004980 S.RESISTOR
R346 7030004990 S.RESISTOR
R347 7030005080 S.RESISTOR
R348 7030005080 S.RESISTOR
R349 7030005710 S.RESISTOR
6 - 5
DESCRIPTION
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 682 X (6.8 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 820 X (82 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 220 X (22 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 181 X (180 Ω)
ERJ2GEJ 220 X (22 Ω)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 562 X (5.6 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 124 X (120 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 105 X (1 MΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 124 X (120 kΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 394 X (390 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 121 X (120 Ω)
S.=Surface mount
