[RF UNIT]

REF ORDER
NO. NO.
RL1 6330001320 AHY103
J1* 6510007020 TMP-J01X-V6
J2* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN)
J121* 6510007020 TMP-J01X-V6
J151* 6510007020 TMP-J01X-V6
J261 6510007900 TBP-P01X-A1
J262* 6510007020 TMP-J01X-V6
J401* 6450001491 HLJ7001-016010 (HONTAINOMI)
J1001* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN)
J1601 6510009870 PD054-02M
J1901 6510007900 TBP-P01X-A1
P261 6510003240 TMP-P01X-A1
P1601 6510018980 PHR-2
P1901 6510003240 TMP-P01X-A1
WS1 8970023952 SX2494 1.5+0.8DB (3)/RF
(Incl. J261, 1601, 1901, P261, 1601, 1901,
W261, 262, 1651, 1652, 1951, 1952, EP2,
MP1902, 1905)
W213 7120000490 ERD25T0
W252 7120000490 ERD25T0
W254 7120000470 ERDS2T0
W261 9014130400 62/99/150/C24/C31
W262 9086700300 WIRE 8
W1651 9023550130 61/99/180/B11/D33
W1652 9086700300 WIRE 8
W1951 9014130400 62/99/150/C24/C31
(incl. J1901,P1901,W1952,EP2,MP1902)
W1952 9086700300 WIRE 8
EP2 6910000630 FSOH070RN
EP261 6910000630 FSOH070RN
MP1 8510000210 194 SHIELD PLATE
MP2 8930055981 SHIELD SPONGE (F)-1
MP121 8510005980 724 SHIELD CASE
MP122 8510005990 724 SHIELD CASE COVER
MP123 8510000180 117 SHIELD PLATE
MP124 8930014140 EARTH SPRING (D)
MP125 8930054521 SHIELD SPONGE (E)-1
MP126 8930055981 SHIELD SPONGE (F)-1
MP127 8930014140 EARTH SPRING (D)
MP128 8930058170 SHIELD SPONGE (O)
MP181 8510005980 724 SHIELD CASE
MP211 8510005150 602 SHIELD CASE
MP212 8510005160 602 SHIELD CASE COVER
MP213 8510002280 VCOSHIELD PLATE (A) (FX-15)
MP214 8930052271 SHIELD SPONGE (D)-1
MP231 8930005320 FILTER SPACER
MP251 8930014140 EARTH SPRING (D)
MP261 8510013560 2355 U-L PLATE
MP281 8510012400 2177 D/A CASE
MP282 8930057760 2494 RF SPRING
MP301 8510000210 194 SHIELD PLATE
MP1101 8510010760 1876 DDS CASE
MP1102 8510010770 1876 DDS COVER
MP1103 8510005330 COIL CASE (SX-644)
MP1201 8510011511 2072 VCO CASE-1
MP1202 8510011521 2072 VCO COVER-1
MP1203 8810003961 SETSCREW (A) 2.6X5 ZC3
MP1204 8510011710 2072 VCO SHIELD
MP1205 8930013520 SPONGE (BJ)
MP1207 8930055981 SHIELD SPONGE (F)-1
MP1208 8930027891 946 EARTH SPRING-1
MP1301 8510010052 1691 SHIELD CASE-2
MP1302 8510010062 1691 SHIELD COVER-2
MP1303 8810003961 SETSCREW (A) 2.6X5 ZC3
MP1401 8510010052 1691 SHIELD CASE-2
MP1402 8510010062 1691 SHIELD COVER-2
MP1403 8810003961 SETSCREW (A) 2.6X5 ZC3
MP1404 8930027891 946 EARTH SPRING-1
MP1501 8510005980 724 SHIELD CASE
MP1502 8510005990 724 SHIELD CASE COVER
MP1601 8510005980 724 SHIELD CASE
MP1602 8510005990 724 SHIELD CASE COVER
MP1603 8930014140 EARTH SPRING (D)
MP1604 8930014140 EARTH SPRING (D)
MP1801 8510005980 724 SHIELD CASE
MP1802 8510005990 724 SHIELD CASE COVER
MP1901 8510000231 220 SHIELD CASE-1
MP1902 8950000180 CABLE TIE -80
MP1903 8930014140 EARTH SPRING (D)
MP1905 8950000180 CABLE TIE -80
DESCRIPTION QTY.
[MAIN UNIT]
REF ORDER
NO. NO.
1 RL740* 6330001320 AHY103
RL781* 6330000540 OMR-109F
1
CP200* 6910009670 HK3-S-T
1
1 CP300* 6910009670 HK3-S-T
CP1460* 6910009670 HK3-S-T
1
1
J100* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN)
1
J120* 6510022601 30FMN-BMTTR-A-TBT (LF) (SN)
1
J140* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN)
1
J160* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN)
1
J180* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN)
1
J250* 6510007020 TMP-J01X-V6
J400* 6510018961 B2B-PH-SM4-TB (LF) (SN)
1
J700* 6450001841 TCS7568-4320177
1
1 J740* 6450000140 HSJ0807-01-010
J741* 6510018961 B2B-PH-SM4-TB (LF) (SN)
J760* 6450000140 HSJ0807-01-010
J761* 6510018971 B4B-PH-SM4-TB (LF) (SN)
J780* 6510023661 TCS4470-0141577
J781* 6510023671 TCS4480-0141577
J782* 6450001130 JPJ2042-01-110
1 J802* 6510018961 B2B-PH-SM4-TB (LF) (SN)
1 J1000* 6510021651 IMSA-9180B-30B-PT1
1 J1001* 6510022811 IMSA-9180B-22B-PT1
1 J1920* 6510019191 52365-0871
1
1 EP2 0880000890 EX-2432 #01
1
MP200 8510000231 220 SHIELD CASE-1
1 MP791 8930014140 EARTH SPRING (D)
1
1
[PA UNIT]
1
REF ORDER
1
NO. NO.
1
1
RL1* 6330001550 JV-12-KT
1
RL2* 6330001430 NA-12W-K
1
RL501* 6330001510 TB1-160
1
RL502* 6330001510 TB1-160
1
RL503* 6330001510 TB1-160
1
RL504* 6330001510 TB1-160
1
RL505* 6330001510 TB1-160
1
RL506* 6330001510 TB1-160
1
RL507* 6330001510 TB1-160
1
RL508* 6330001510 TB1-160
1
RL509* 6330001510 TB1-160
1
RL510* 6330001510 TB1-160
1
RL511* 6330001510 TB1-160
2
RL512* 6330001510 TB1-160
1
RL513* 6330001330 AG201344
1
RL514* 6330001330 AG201344
1
RL601* 6330001530 AE5349 (NR-HD 5V)
1
1
J1* 6510007020 TMP-J01X-V6
1
J5* 6510020001 52808-3071
1
J10* 6510003081 RT01T-1.0B (LF)
1
J21* 6510021531 IMSA-9230B-1-04Z024-PT1
1
J22* 6510021531 IMSA-9230B-1-04Z024-PT1
1
J23* 6510021531 IMSA-9230B-1-04Z024-PT1
4
J24* 6510021531 IMSA-9230B-1-04Z024-PT1
1
J502 6510007900 TBP-P01X-A1
1
J601 6510007900 TBP-P01X-A1
1
1
P501 6510003240 TMP-P01X-A1
1
P601 6510003240 TMP-P01X-A1
1
3
F1* 5210000061 FGB 5A PBF
1
F2* 5220000230 S-N5054 #01
1
F3* 5220000230 S-N5054 #01
3
1
WS1 8970022760 SX1876 J(1)/PA (Incl. W14)
1
WS2 8970023991 SX2494 1.5D-1 (2)/PA
1
(Incl. J502, P501, 602, W550, 650)
1
1
W1* 7030003860 ERJ3GE-JPW
1
W3* 7030003860 ERJ3GE-JPW
1
W7 7120000490 ERD25T0
1
W8 7120000490 ERD25T0
1
W14 9016910440 23/06/050/D21/W05
1
W29 9040401015 74/98/045/X98/X98
2
W504* 7030003860 ERJ3GE-JPW
1
W550 9009130242 62/99/320/C24/C31
2
W551 9086700300 WIRE 8
W601 7120000490 ERD25T0
W602 7120000490 ERD25T0
W650 9009130030 62/99/300/C24/C31
W651 9086700300 WIRE 8
EP2* 6910000610 FSOH050RN01
EP3* 6910000610 FSOH050RN01
EP6 6910011330 OT-009 M3
EP7 6910011330 OT-009 M3
EP650 6910000630 FSOH070RN
MP2 8930046570 2072 PA PLATE
7 - 5
