Icom IC-T81E Service Manual page 27

[RF UNIT]
REF ORDER
NO. NO.
Q826 1590001910 S.TRANSISTOR UN911D (TX)
Q827 1590001970 S.TRANSISTOR UN921E (TX)
Q828 1590001910 S.TRANSISTOR UN911D (TX)
Q829 1590001970 S.TRANSISTOR UN921E (TX)
Q901 1590001150 S.TRANSISTOR UN9211 (TX)
Q902 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q903 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q904 1590001150 S.TRANSISTOR UN9211 (TX)
Q905 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q906 1590001150 S.TRANSISTOR UN9211 (TX)
Q907 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q908 1590001150 S.TRANSISTOR UN9211 (TX)
Q909 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q910 1590001150 S.TRANSISTOR UN9211 (TX)
Q911 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q912 1590001860 S.TRANSISTOR UN9215 (TX)
Q913 1590002160 S.TRANSISTOR XP6401-(TX)
Q921 1590002600 S.FET
Q922 1560001060 S.FET
Q923 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q924 1590001860 S.TRANSISTOR UN9215 (TX)
Q925 1590001860 S.TRANSISTOR UN9215 (TX)
Q926 1590001860 S.TRANSISTOR UN9215 (TX)
Q927 1590001860 S.TRANSISTOR UN9215 (TX)
Q928 1590001150 S.TRANSISTOR UN9211 (TX)
Q929 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q931 1590001660 S.TRANSISTOR XP4312 (TX)
Q932 1540000350 S.TRANSISTOR 2SD2216-S (TX)
D1 1750000540 S.DIODE
D4 1790001240 S.DIODE
D5 1790000860 S.DIODE
D6 1790000670 S.DIODE
D10 1790001250 S.DIODE
D12 1790000850 S.DIODE
D31 1790001260 S.DIODE
D32 1790001620 S.DIODE
D51 1790001260 S.DIODE
D52 1790001260 S.DIODE
D53 1790001620 S.DIODE
D101 1790001620 S.DIODE
D102 1790001620 S.DIODE
D103 1790001260 S.DIODE
D106 1720000370 S.VARICAP
D107 1720000370 S.VARICAP
D108 1790001620 S.DIODE
D132 1790001620 S.DIODE
D134 1790001620 S.DIODE
D141 1790001620 S.DIODE
D142 1790001250 S.DIODE
D143 1790001250 S.DIODE
D201 1790001620 S.DIODE
D202 1720000730 S.VARICAP
D203 1720000730 S.VARICAP
D204 1790001620 S.DIODE
D302 1790001260 S.DIODE
D303 1790001260 S.DIODE
D304 1790001620 S.DIODE
D306 1750000610 S.VARICAP
D309 1750000610 S.VARICAP
D310 1750000610 S.VARICAP
D311 1790001620 S.DIODE
D341 1720000660 S.VARICAP
D402 1790001260 S.DIODE
D403 1790001260 S.DIODE
D404 1790001260 S.DIODE
D405 1790001620 S.DIODE
D406 1790001250 S.DIODE
D407 1790001260 S.DIODE
D501 1790001620 S.DIODE
D503 1790001620 S.DIODE
D505 1790001620 S.DIODE
D507 1790001620 S.DIODE
D508 1790000850 S.DIODE
D509 1790001260 S.DIODE
D510 1790001200 S.DIODE
D601 1750000360 S.DIODE
D602 1750000360 S.DIODE
D721 1750000360 S.DIODE
D801 1790000850 S.DIODE
D802 1790001260 S.DIODE
DESCRIPTION
MRF9745 T1
2SK3075 (TE12L)
RB060L-40 TE-25
MA2S728-(TX)
MA133 (TX)
SB07-03C-TB
MA2S111-(TX)
MA132WK (TX)
MA2S077-(TX)
1SV308 (TPL3)
MA2S077-(TX)
MA2S077-(TX)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
MA2S077-(TX)
HVU350TRF
HVU350TRF
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
MA2S111-(TX)
MA2S111-(TX)
1SV308 (TPL3)
MA2S30400L
MA2S30400L
1SV308 (TPL3)
MA2S077-(TX)
MA2S077-(TX)
1SV308 (TPL3)
MA2SV0500L
MA2SV0500L
MA2SV0500L
1SV308 (TPL3)
1SV288 (TPH2)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
1SV308 (TPL3)
MA2S111-(TX)
MA2S077-(TX)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
MA132WK (TX)
MA2S077-(TX)
MA6S121 (TX)
1SS364 (TE85L)
1SS364 (TE85L)
1SS364 (TE85L)
MA132WK (TX)
MA2S077-(TX)
[RF UNIT]
REF ORDER
NO. NO.
D803 1790001260 S.DIODE
D804 1790001260 S.DIODE
D805 1790001260 S.DIODE
D806 1790001260 S.DIODE
D807 1790001260 S.DIODE
D808 1790001260 S.DIODE
D810 1790001200 S.DIODE
D901 1790000860 S.DIODE
D902 1750000530 S.DIODE
D903 1790001260 S.DIODE
D904 1750000530 S.DIODE
D906 1790001620 S.DIODE
D907 1790001620 S.DIODE
D908 1790001260 S.DIODE
D909 1750000530 S.DIODE
D910 1750000530 S.DIODE
D913 1790001620 S.DIODE
D914 1790001620 S.DIODE
D918 1790001620 S.DIODE
D919 1730002360 S.ZENER
FI51 2040001360 S.FILTER
FI52 2040001360 S.FILTER
FI401 2040001020 S.SAW
2040001000 S.SAW
FI601 2010002340 S.FILTER
FI602 2020001500 S.CERAMIC
X1 6050010520 S.XTAL
L1 6200008510 S.COIL
L2 6200008440 S.COIL
L3 6200008440 S.COIL
L4 6200008240 S.COIL
L5 6200008540 S.COIL
L6 6200008690 S.COIL
L7 6200008530 S.COIL
L8 6200008210 S.COIL
L9 6200008220 S.COIL
L10 6200008150 S.COIL
L11 6200008170 S.COIL
L12 6200008170 S.COIL
L13 6200008080 S.COIL
L14 6200008190 S.COIL
L15 6200008180 S.COIL
L16 6200008180 S.COIL
L17 6200008360 S.COIL
L18 6200008360 S.COIL
L51 6200008680 S.COIL
L52 6200008490 S.COIL
L53 6200008680 S.COIL
L54 6200008680 S.COIL
L55 6200008930 S.COIL
L56 6200008680 S.COIL
L57 6200008520 S.COIL
L58 6200005650 S.COIL
L59 6200005600 S.COIL
L61 6200008420 S.COIL
L62 6200003590 S.COIL
L63 6200003590 S.COIL
L64 6200005610 S.COIL
L65 6200005490 S.COIL
L101 6200007790 S.COIL
L102 6200007790 S.COIL
L108 6200007120 S.COIL
L109 6200007360 S.COIL
L110 6200007360 S.COIL
L121 6200005610 S.COIL
L122 6200005630 S.COIL
L123 6200006770 S.COIL
L124 6200005590 S.COIL
L125 6200005590 S.COIL
L134 6200004480 S.COIL
L135 6200007800 S.COIL
L136 6200005720 S.COIL
L137 6200005710 S.COIL
L138 6200007700 S.COIL
L139 6200005630 S.COIL
L142 6200005730 S.COIL
6 - 4
DESCRIPTION
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA6S121 (TX)
MA133 (TX)
1SV271 (TPH3)
MA2S077-(TX)
1SV271 (TPH3)
1SV308 (TPL3)
1SV308 (TPL3)
MA2S077-(TX)
1SV271 (TPH3)
1SV271 (TPH3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
MA8062-M (TX)
LFL30-13C1270B060
LFL30-13C1270B060
EFCH445MWNP1 [USA-1] only
EFCH435MWNP1 [other]
FL-299 (69.450 MHz)
SFECV13.35MA
CR-638 (13.800 MHz)
0.30-0.9-4TR 10.5N
LQN21A 8N2D04
LQN21A 8N2D04
0.30-0.9-5TL 14N
0.26-0.9-6TR 19N
0.26-0.9-7TR 23N
0.30-1.0-4TR 12N
0.45-1.5-5TL 23.2N
0.40-1.4-5TR 21N
0.35-1.6-7TL 44N
0.35-1.6-8TL 54N
0.35-1.6-8TL 54N
LQN21A R22J04
0.25-1.9-8TL 80N
0.25-1.9-10TL 107N
0.25-1.9-10TL 107N
0.25-1.9-13TL
0.25-1.9-13TL
0.26-0.8-3TR 6.8N
0.30-0.9-3TR 7.5N
0.26-0.8-3TR 6.8N
0.26-0.8-3TR 6.8N
0.26-0.7-3TL 5.6N
0.26-0.8-3TR 6.8N
0.30-0.7-3TR 4.9N
ELJRE 8N2Z-F
ELJRE 3N3Z-F
HF50ACC 453215P-T
EXCCL3225U1
EXCCL3225U1
ELJRE 3N9Z-F
NL 322522T-331J
LQN21A R15J04
LQN21A R15J04
ELJND 1R0J 1U
ELJND R47J 0.47U
ELJND R47J 0.47U
ELJRE 3N9Z-F
ELJRE 5N6Z-F
ELJRE 1N5Z-F
ELJRE 2N7Z-F
ELJRE 2N7Z-F
MLF1608D R82K-T
LQN21A R18J04
ELJRE 33NG-F
ELJRE 27NG-F
LQN21A 22NJ04
ELJRE 5N6Z-F
ELJRE 39NG-F
S.=Surface mount
