Icom IC-T81E Service Manual page 33

[VCO BOARD]
REF ORDER
NO. NO.
R314 7030005290 S.RESISTOR
R315 7030004980 S.RESISTOR
R316 7030004990 S.RESISTOR
R317 7030005070 S.RESISTOR
R318 7030005300 S.RESISTOR
R319 7030004980 S.RESISTOR
R321 7030005120 S.RESISTOR
R322 7030004970 S.RESISTOR
R323 7030005590 S.RESISTOR
R324 7030009140 S.RESISTOR
R325 7030009140 S.RESISTOR
R326 7030004970 S.RESISTOR
R327 7030004980 S.RESISTOR
R328 7030007270 S.RESISTOR
R329 7030005070 S.RESISTOR
R330 7030005300 S.RESISTOR
R360 7030005050 S.RESISTOR
R361 7030005220 S.RESISTOR
R362 7030009140 S.RESISTOR
R363 7030009160 S.RESISTOR
R364 7030007290 S.RESISTOR
R365 7030005530 S.RESISTOR
R366 7030005060 S.RESISTOR
R367 7030008010 S.RESISTOR
R368 7030005570 S.RESISTOR
R369 7030004970 S.RESISTOR
R371 7030004980 S.RESISTOR
R372 7030005090 S.RESISTOR
R373 7030004980 S.RESISTOR
R374 7030005090 S.RESISTOR
C301 4030013850 S.CERAMIC
C302 4030013850 S.CERAMIC
C303 4030013850 S.CERAMIC
C304 4030014020 S.CERAMIC
C305 4030014020 S.CERAMIC
C306 4030013850 S.CERAMIC
C307 4030014280 S.CERAMIC
C308 4030013850 S.CERAMIC
C309 4030013850 S.CERAMIC
C310 4030013850 S.CERAMIC
C311 4030013850 S.CERAMIC
C312 4030013850 S.CERAMIC
C313 4030013980 S.CERAMIC
C314 4030013980 S.CERAMIC
C315 4030013850 S.CERAMIC
C316 4030014280 S.CERAMIC
C317 4030013850 S.CERAMIC
C318 4030013850 S.CERAMIC
C319 4030013850 S.CERAMIC
C320 4030013850 S.CERAMIC
C321 4030014150 S.CERAMIC
C322 4030014180 S.CERAMIC
C323 4030013850 S.CERAMIC
C324 4030013980 S.CERAMIC
C325 4030013980 S.CERAMIC
C326 4030013850 S.CERAMIC
C327 4030014420 S.CERAMIC
C328 4030013850 S.CERAMIC
C329 4030013850 S.CERAMIC
C330 4030013850 S.CERAMIC
C331 4030013850 S.CERAMIC
C332 4030013850 S.CERAMIC
C333 4030013850 S.CERAMIC
C334 4030013850 S.CERAMIC
C360 4030013970 S.CERAMIC
C361 4030013850 S.CERAMIC
C362 4030013850 S.CERAMIC
C363 4030009820 S.CERAMIC
C364 4030014130 S.CERAMIC
C365 4030014020 S.CERAMIC
C366 4030014100 S.CERAMIC
C367 4030013850 S.CERAMIC
C368 4030013850 S.CERAMIC
C369 4030014100 S.CERAMIC
C370 4550006120 S.TANTALUM
C371 4030014090 S.CERAMIC
C372 4030013850 S.CERAMIC
C373 4030013980 S.CERAMIC
C374 4030014050 S.CERAMIC
C375 4030013850 S.CERAMIC
DESCRIPTION
ERJ2GEJ 682 X (6.8 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 150 X (15 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 680 X (68 Ω)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 150 X (15 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 181 X (180 Ω)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 123 (12 kΩ)
ERJ2GEJ 820 X (82 Ω)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 104 X (100 kΩ)
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H020BCQ
ECUE1H020BCQ
ECUE1E102KBQ
ECUE1H0R3BCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H010BCQ
ECUE1H010BCQ
ECUE1E102KBQ
ECUE1H0R3BCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H220JCQ
ECUE1H470JCQ
ECUE1E102KBQ
ECUE1H010BCQ
ECUE1H010BCQ
ECUE1E102KBQ
ECUE1H0R5BCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
ECUE1E102KBQ
C1005 JB 1C 103K-T-A
ECUE1H120JCQ
ECUE1H020BCQ
ECUE1H070CCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H070CCQ
TEMSVA 0G 226M-8L
ECUE1H060CCQ
ECUE1E102KBQ
ECUE1H010BCQ
ECUE1H030BCQ
ECUE1E102KBQ
[VCO BOARD]
REF ORDER
NO. NO.
C376 4030014070 S.CERAMIC
C377 4030014110 S.CERAMIC
C378 4030014000 S.CERAMIC
C379 4030010080 S.CERAMIC
C380 4030014050 S.CERAMIC
C381 4030014000 S.CERAMIC
C382 4030013980 S.CERAMIC
C383 4030014050 S.CERAMIC
C384 4030014420 S.CERAMIC
C385 4030014020 S.CERAMIC
C386 4030014050 S.CERAMIC
C387 4030013850 S.CERAMIC
C388 4030014020 S.CERAMIC
C389 4030013970 S.CERAMIC
J301 6910012160 CONNECTOR
J302 6910011770 CONNECTOR
EP1 0910051333 PCB
6 - 10
DESCRIPTION
ECUE1H040BCQ
ECUE1H080CCQ
ECUE1H1R5BCQ
C1005 CH 1E 240J-T-A
ECUE1H030BCQ
ECUE1H1R5BCQ
ECUE1H010BCQ
ECUE1H030BCQ
ECUE1H0R5BCQ
ECUE1H020BCQ
ECUE1H030BCQ
ECUE1E102KBQ
ECUE1H020BCQ
C1005 JB 0J 104K-T-N
IMSA-9230B-1-07Z057-T
IMSA-9230B-1-10Z057-T
B 5137C
S.=Surface mount
