• RF UNIT BOTTOM VIEW
• RF UNIT TOP VIEW
• LOGIC UNIT TOP VIEW
L702
Detector Output voltage adjustment
Q
Detector Output voltage check point
12LV
PLL lock voltage check point
(for 1200 MHz)
ULV
PLL lock voltage check point
(for 440 MHz)
VLV
PLL lock voltage check point
(for 50 MHz RX, WFM and 144 MHz)
6MLV
PLL lock voltage check point
(for 50 MHz TX)
