Icom IC-T81E Service Manual page 29

[RF UNIT]
REF ORDER
NO. NO.
R351 7030005300 S.RESISTOR
R401 7030007300 S.RESISTOR
R402 7030005120 S.RESISTOR
R403 7030007300 S.RESISTOR
R404 7030005060 S.RESISTOR
R409 7030007270 S.RESISTOR
R410 7030004980 S.RESISTOR
R413 7030005040 S.RESISTOR
R414 7030005040 S.RESISTOR
R501 7030007300 S.RESISTOR
R502 7030005070 S.RESISTOR
R503 7030007280 S.RESISTOR
R504 7030004980 S.RESISTOR
R505 7030005040 S.RESISTOR
R506 7030005090 S.RESISTOR
R507 7030007290 S.RESISTOR
R508 7030005090 S.RESISTOR
R509 7030007290 S.RESISTOR
R510 7030005040 S.RESISTOR
R511 7030005040 S.RESISTOR
R512 7030005050 S.RESISTOR
R513 7030005040 S.RESISTOR
R608 7030005040 S.RESISTOR
R609 7030005040 S.RESISTOR
R610 7030005040 S.RESISTOR
R611 7030007280 S.RESISTOR
R612 7030005040 S.RESISTOR
R613 7030005040 S.RESISTOR
R614 7030005040 S.RESISTOR
R615 7030008280 S.RESISTOR
R616 7030008370 S.RESISTOR
R701 7030005090 S.RESISTOR
R702 7030005000 S.RESISTOR
R721 7030005040 S.RESISTOR
R722 7030005240 S.RESISTOR
R725 7030005040 S.RESISTOR
R726 7030005040 S.RESISTOR
R727 7030005000 S.RESISTOR
R728 7030005040 S.RESISTOR
R742 7030005050 S.RESISTOR
R802 7030005090 S.RESISTOR
R803 7030005050 S.RESISTOR
R804 7030005040 S.RESISTOR
R805 7030005040 S.RESISTOR
R806 7030005040 S.RESISTOR
R807 7030005240 S.RESISTOR
R811 7030005720 S.RESISTOR
R812 7030005080 S.RESISTOR
R813 7030005240 S.RESISTOR
R814 7510001240 S.THEMISTOR
R815 7030007300 S.RESISTOR
R816 7030005290 S.RESISTOR
R817 7030008280 S.RESISTOR
R818 7030005050 S.RESISTOR
R819 7030005050 S.RESISTOR
R820 7030005050 S.RESISTOR
R821 7030005290 S.RESISTOR
R826 7030004980 S.RESISTOR
R827 7030005080 S.RESISTOR
R828 7030004990 S.RESISTOR
R829 7030004970 S.RESISTOR
R838 7030005120 S.RESISTOR
R839 7030005300 S.RESISTOR
R841 7030007280 S.RESISTOR
R842 7030007280 S.RESISTOR
R844 7030007280 S.RESISTOR
R845 7030007280 S.RESISTOR
R847 7030005300 S.RESISTOR
7030005570 S.RESISTOR
R848 7030005300 S.RESISTOR
7030007280 S.RESISTOR
R849 7030007300 S.RESISTOR
R850 7030005040 S.RESISTOR
R851 7030008280 S.RESISTOR
R852 7030005120 S.RESISTOR
R853 7030005050 S.RESISTOR
R854 7030005050 S.RESISTOR
R855 7030005290 S.RESISTOR
DESCRIPTION
ERJ2GEJ 150 X (15 Ω)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 271 X (270 Ω)
ERJ2GEJ 561 X (560 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERTJ0EV 473J (47K)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 682 X (6.8 kΩ)
ERJ2GEJ 271 X (270 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 682 X (6.8 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 150 X (15 Ω)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 150 X (15 Ω)
[AUS], [SEA], [USA-1]
ERJ2GEJ 820 X (82 Ω)
[EUR], [UK], [ITA]
ERJ2GEJ 150 X (15 Ω)
[AUS], [SEA], [USA-1]
ERJ2GEJ 331 X (330 Ω)
[EUR], [UK], [ITA]
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 271 X (270 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 682 X (6.8 kΩ)
[RF UNIT]
REF ORDER
NO. NO.
R857 7030008370 S.RESISTOR
R862 7030005290 S.RESISTOR
R864 7030004980 S.RESISTOR
R865 7030004980 S.RESISTOR
R866 7030005240 S.RESISTOR
R867 7030004990 S.RESISTOR
R868 7030004980 S.RESISTOR
R869 7030005120 S.RESISTOR
R870 7030004970 S.RESISTOR
R871 7030007340 S.RESISTOR
R872 7030008010 S.RESISTOR
R874 7030005050 S.RESISTOR
R875 7030005220 S.RESISTOR
R876 7030009140 S.RESISTOR
R877 7030005240 S.RESISTOR
R881 7030004990 S.RESISTOR
R882 7030005600 S.RESISTOR
R884 7030004990 S.RESISTOR
R885 7030005060 S.RESISTOR
R887 7030005040 S.RESISTOR
R888 7030005040 S.RESISTOR
R889 7030004990 S.RESISTOR
R890 7030007350 S.RESISTOR
R892 7030005040 S.RESISTOR
R893 7030005040 S.RESISTOR
R894 7030007270 S.RESISTOR
R895 7030005060 S.RESISTOR
R897 7030005040 S.RESISTOR
R898 7030005040 S.RESISTOR
R899 7030005040 S.RESISTOR
R900 7030005040 S.RESISTOR
R901 7030005000 S.RESISTOR
R902 7030005000 S.RESISTOR
R903 7030005040 S.RESISTOR
R904 7030005000 S.RESISTOR
R905 7030005040 S.RESISTOR
R906 7030005000 S.RESISTOR
R907 7030005040 S.RESISTOR
R908 7030005000 S.RESISTOR
R909 7030005040 S.RESISTOR
R910 7030005120 S.RESISTOR
R911 7030007330 S.RESISTOR
R912 7030008400 S.RESISTOR
R913 7030005050 S.RESISTOR
R914 7030005050 S.RESISTOR
R915 7030005050 S.RESISTOR
R916 7030005160 S.RESISTOR
R917 7030005220 S.RESISTOR
R918 7030005600 S.RESISTOR
R919 7030005040 S.RESISTOR
R923 7030005600 S.RESISTOR
R924 7030005090 S.RESISTOR
R925 7030004980 S.RESISTOR
R928 7030003260 S.RESISTOR
R929 7030005120 S.RESISTOR
R930 7030005090 S.RESISTOR
R931 7030005090 S.RESISTOR
R932 7030005050 S.RESISTOR
R933 7030007270 S.RESISTOR
R934 7030007270 S.RESISTOR
R935 7030005240 S.RESISTOR
R936 7030005590 S.RESISTOR
R938 7030007260 S.RESISTOR
R939 7030007270 S.RESISTOR
R940 7030005240 S.RESISTOR
R942 7030007270 S.RESISTOR
R943 7030005240 S.RESISTOR
R944 7030005240 S.RESISTOR
R945 7030007270 S.RESISTOR
R946 7030004980 S.RESISTOR
R949 7030004010 S.RESISTOR
R951 7030007280 S.RESISTOR
R952 7030005000 S.RESISTOR
R953 7030005040 S.RESISTOR
R954 7030005000 S.RESISTOR
C1 4030013980 S.CERAMIC
C2 4030014050 S.CERAMIC
C3 4030014050 S.CERAMIC
C4 4030014110 S.CERAMIC
C5 4030014190 S.CERAMIC
6 - 6
DESCRIPTION
ERJ2GEJ 561 X (560 Ω)
ERJ2GEJ 682 X (6.8 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 123 (12 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 393 X (39 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ1WRSJR15U (0.15 Ω)
ERJ2GEJ 182 X (1.8 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 105 X (1 MΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ3GEYJ 330 V (33 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 680 X (68 Ω)
ERJ2GEJ 330 X (33 Ω)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ3GEYJ 2R2 V (2.2 Ω)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 471 X (470 Ω)
ECUE1H010BCQ
ECUE1H030BCQ
ECUE1H030BCQ
ECUE1H080CCQ
ECUE1H680JCQ
S.=Surface mount
