Logic Unit - Icom IC-T81E Service Manual

SECTION 6 PARTS LIST

[LOGIC UNIT]

REF ORDER
NO. NO.
IC1 1140008110 S.IC
1140008100 S.IC
IC2 1130009160 S.IC
IC3 1110004890 S.IC
IC4 1130006220 S.IC
IC5 1110004530 S.IC
IC141 1180001720 S.IC
IC142 1110004540 S.IC
IC201 1110001810 S.IC
IC202 1110004520 S.IC
IC203 1110002750 S.IC
IC241 1110003780 S.IC
IC301 1110004110 S.IC
IC701 1110003490 S.IC
IC751 1130004200 S.IC
Q1 1590001690 S.TRANSISTOR UN9115 (TX)
Q3 1590001980 S.TRANSISTOR XP4315 (TX)
Q7 1590001170 S.TRANSISTOR XP1501-(TX) AB
Q8 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q141 1590001140 S.TRANSISTOR UN9210 (TX)
Q142 1590001170 S.TRANSISTOR XP1501-(TX) AB
Q145 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q151 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q201 1520000650 S.TRANSISTOR 2SB1201-S-TL
Q202 1590001170 S.TRANSISTOR XP1501-(TX) AB
Q301 1590001690 S.TRANSISTOR UN9115 (TX)
Q302 1520000430 S.TRANSISTOR 2SB1462-R (TX)
Q303 1590001440 S.TRANSISTOR UN9214 (TX)
Q304 1550000010 S.FET
Q305 1550000010 S.FET
Q306 1550000010 S.FET
Q307 1590001440 S.TRANSISTOR UN9214 (TX)
Q308 1590001210 S.TRANSISTOR XP5601-(TX) AB
Q309 1550000010 S.FET
Q341 1590001440 S.TRANSISTOR UN9214 (TX)
Q361 1550000010 S.FET
Q602 1590001690 S.TRANSISTOR UN9115 (TX)
Q603 1590001660 S.TRANSISTOR XP4312 (TX)
Q702 1590001690 S.TRANSISTOR UN9115 (TX)
Q751 1590001170 S.TRANSISTOR XP1501-(TX) AB
Q752 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q753 1590001690 S.TRANSISTOR UN9115 (TX)
Q754 1540000350 S.TRANSISTOR 2SD2216-S (TX)
D2 1790000970 S.DIODE
D3 1790001250 S.DIODE
D4 1790001250 S.DIODE
D51 1790000820 S.DIODE
1790000830 S.DIODE
1790000850 S.DIODE
D52 1790000830 S.DIODE
D53 1790000850 S.DIODE
D55 1790001250 S.DIODE
D58 1790001200 S.DIODE
D59 1790001200 S.DIODE
D61 1790001250 S.DIODE
D141 1790001250 S.DIODE
D143 1790001250 S.DIODE
D144 1790001240 S.DIODE
D151 1730002330 S.ZENER
D152 1790001250 S.DIODE
D304 1730000020 S.ZENER
D701 1750000360 S.DIODE
D702 1750000360 S.DIODE
FI701 2020001480 S.CERAMIC
X1 6050010530 S.XTAL
DESCRIPTION
M38267E8GP [USA-1] only
M38267M8L-230GP [other]
X24320S8I-2.5T4
XC6371A500PR
TC4W53FU (TE12L)
M62368GP 70ED
S-81332HG-KC-T1
S-80928ALMP-DAR-T2
TA7368F (TP1)
M5222FP 600C
TA75S01F (TE85R)
NJM2902V-TE1
BA4510F-T1
TA31136FN (D,EL)
TC4S66F (TE85R)
2SJ364-Q (TX)
2SJ364-Q (TX)
2SJ364-Q (TX)
2SJ364-Q (TX)
2SJ364-Q (TX)
MA729 (TX)
MA2S111-(TX)
MA2S111-(TX)
MA132K (TX) [UK], [AUS]
MA132HK (TX) [EUR], [USA-1]
MA132WK (TX) [SEA]
MA132HK (TX)
[ITA], [AUS], [SEA], [USA-1]
MA132WK (TX) except [ITA]
MA2S111-(TX) except [ITA]
MA6S121 (TX)
MA6S121 (TX)
MA2S111-(TX) except [ITA]
MA2S111-(TX)
MA2S111-(TX)
MA2S728-(TX)
MA8100-M (TX)
MA2S111-(TX)
RD5.1M-T2B3
1SS364 (TE85L)
1SS364 (TE85L)
PBFC450R15DR
CR-639 (5.039 MHz)
[LOGIC UNIT]
REF ORDER
NO. NO.
L1 6200006720 S.COIL
L2 6200003550 S.COIL
L3 6200001820 S.COIL
L702 6150005010 S.COIL
R1 7510000910 S.THERMISTOR NTCCF2012 4AH 473KC-T
R2 7030005090 S.RESISTOR
R4 7030008280 S.RESISTOR
R5 7030008280 S.RESISTOR
R8 7030005050 S.RESISTOR
R9 7030005110 S.RESISTOR
R10 7030005220 S.RESISTOR
R12 7030005840 S.RESISTOR
R13 7030005840 S.RESISTOR
R14 7030005840 S.RESISTOR
R16 7030005050 S.RESISTOR
R17 7030005090 S.RESISTOR
R18 7030005040 S.RESISTOR
R19 7030005040 S.RESISTOR
R21 7030005120 S.RESISTOR
R22 7030005120 S.RESISTOR
R23 7030005120 S.RESISTOR
R24 7030005120 S.RESISTOR
R25 7030005120 S.RESISTOR
R26 7030005040 S.RESISTOR
R27 7030005120 S.RESISTOR
R28 7030005120 S.RESISTOR
R29 7030005120 S.RESISTOR
R30 7030005120 S.RESISTOR
R31 7030005120 S.RESISTOR
R32 7030005120 S.RESISTOR
R33 7030005120 S.RESISTOR
R34 7030005120 S.RESISTOR
R35 7030005120 S.RESISTOR
R36 7030005120 S.RESISTOR
R37 7030005120 S.RESISTOR
R38 7030005090 S.RESISTOR
R39 7030005090 S.RESISTOR
R42 7030008280 S.RESISTOR
R51 7030005160 S.RESISTOR
R53 7030005110 S.RESISTOR
R54 7030005110 S.RESISTOR
R55 7030005110 S.RESISTOR
R56 7030005040 S.RESISTOR
R141 7030007340 S.RESISTOR
R142 7030005830 S.RESISTOR
R143 7030005050 S.RESISTOR
R144 7030005040 S.RESISTOR
R145 7030005050 S.RESISTOR
R146 7030005160 S.RESISTOR
R148 7030008270 S.RESISTOR
R151 7030005120 S.RESISTOR
R153 7030005240 S.RESISTOR
R154 7030005050 S.RESISTOR
R196 7030005110 S.RESISTOR
R197 7030005050 S.RESISTOR
R201 7030005530 S.RESISTOR
R202 7030007270 S.RESISTOR
R203 7030000240 S.RESISTOR
R204 7030000240 S.RESISTOR
R205 7030000240 S.RESISTOR
R206 7030005040 S.RESISTOR
R207 7030005160 S.RESISTOR
R208 7030005050 S.RESISTOR
R209 7030005120 S.RESISTOR
R210 7030005950 S.RESISTOR
R211 7030005820 S.RESISTOR
R212 7030005220 S.RESISTOR
R213 7030005830 S.RESISTOR
R214 7030008270 S.RESISTOR
R215 7030005040 S.RESISTOR
R241 7030005160 S.RESISTOR
R242 7030005170 S.RESISTOR
R243 7030005080 S.RESISTOR
R244 7030005080 S.RESISTOR
6 - 1
DESCRIPTION
5CA-395KN-0369AQ=P3
MLF1608A 4R7K-T
LQH 3N 331K 04
LS-528 (637AN-0223GW=P3)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 271 X (270 Ω)
ERJ2GEJ 271 X (270 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 223 X (22 kΩ)
RR0510R-473-D (47 kΩ)
RR0510R-473-D (47 kΩ)
RR0510R-473-D (47 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 271 X (270 Ω)
ERJ2GEJ 105 X (1 MΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 153 X (15 kΩ)
RR0510R-223-D (22 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 105 X (1 MΩ)
RR0510R-104-D (100 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 151 X (150 Ω)
MCR10EZHJ 68 Ω (680)
MCR10EZHJ 68 Ω (680)
MCR10EZHJ 68 Ω (680)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 105 X (1 MΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 102 X (1 kΩ)
RR0510R-123-D (12 kΩ)
RR0510P-103-D (10 kΩ)
ERJ2GEJ 223 X (22 kΩ)
RR0510R-223-D (22 kΩ)
RR0510R-104-D (100 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 105 X (1 MΩ)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 823 X (82 kΩ)
S.=Surface mount
