8.9.1 TL895 Robotic Controller Required Firmware

Robotic firmware version N2.20 is the minimum firmware revision supported
in a TruCluster Server cluster. For information on upgrading the robotic
firmware, see the Flash Download section of the TL895 DLT Tape Library
Diagnostic Software User's Manual.

8.9.2 Setting the TL895 Tape Library SCSI IDs

The library and each tape drive must have the SCSI ID set (unless the
default is sufficient). Table 8–5 lists the TL895 default SCSI IDs.
Table 8–5: TL895 Default SCSI ID Settings
SCSI Device
Library
Drive 0
Drive 1
Drive 2
Drive 3
Drive 4
Drive 5
Drive 6
The SCSI IDs must be set mechanically by the rotary switches, and
electronically from the control panel. After you have set the SCSI IDs from
the switches, power up the library and electronically set the SCSI IDs.
To electronically set the SCSI ID for the TL895 library and tape drives,
follow these steps:
1. At the control panel, press the Operator tab.
2. On the Enter Password screen, enter the operator password. The
default operator password is 1234. The lock icon is unlocked and shows
an O to indicate that you have operator-level security clearance.
3. On the Operator screen, press the Configure Library button. The
Configure Library screen displays the current library configuration.
____________________
You can configure the library model number, number of
storage bins, number of drives, library SCSI ID, and tape
drive SCSI IDs from the Configure Library screen.
SCSI ID
0
1
2
3
4
5
1
2
Note _____________________
Configuring a Shared SCSI Bus for Tape Drive Use 8–37
