Figure 8–9: TruCluster Server Cluster with a TL892 on Two Shared SCSI
Buses
KZPSA adapter,
trilink connector,
and H879 terminator
T
T
Memory Channel link cable
AlphaServer 2100A
BN21K or
BN21L cable

8.7 Preparing the TL890 DLT MiniLibrary Expansion Unit

The topics in this section provide information on preparing the TL890 DLT
MiniLibrary expansion unit with the TL891 and TL892 DLT MiniLibraries
for use on a shared SCSI bus.
______________________
To achieve system performance capabilities, we recommend
placing no more than two TZ89 drives on a SCSI bus, and also
recommend that no shared storage be placed on the same SCSI
bus with a tape library.
DWZZA-VA,
trilink connector,
BN21K or BN21L cables
and H879 terminator
Memory
Channel
adapters
BA350
AlphaServer 2100A
Library
Robotics
Note _______________________
Configuring a Shared SCSI Bus for Tape Drive Use 8–23
DWZZA-VA,
trilink connector,
and H879 terminator
T T
1 1
2 2
3 3
4 4
5 5
BA350
DLT1
H879-AA
terminators
DLT2
Expansion
Unit
Interface
1 Ft
TL892
SCSI Bus
Jumper
ZK-1357U-AI
