Table 2–1: AlphaServer Systems Supported for Fibre Channel
AlphaServer
AlphaServer 800
AlphaServer 1200
AlphaServer 4000, 4000A, or 4100
Compaq AlphaServer DS10
Compaq AlphaServer DS20 and DS20E
Compaq AlphaServer ES40
AlphaServer 8200 or 8400
Compaq AlphaServer GS60, GS60E,
a
and GS140
a The KGPSA-BC/CA PCI-to-Fibre Channel adapters are only supported on the DWLPB PCIA option;
they are not supported on the DWLPA.
The following requirements and restrictions apply to the use of Fibre
Channel with the TruCluster Server:
• The HSG80 requires Array Control Software (ACS) Version 8.5.
• A maximum of four member systems is supported.
• The only supported Fibre Channel adapters are the KGPSA-BC and
KGPSA-CA PCI-to-Fibre Channel host bus adapters.
• The only Fibre Channel switches supported are the 8/16 Port DSGGA or
DSGGB Fibre Channel switches.
• The Fibre Channel switches support both shortwave (GBIC-SW) and
longwave (GBIC-LW) Giga Bit Interface Converter (GBIC) modules.
The GBIC-SW module supports 50-micron, multimode fibre cables with
the standard subscriber connector (SC connector) in lengths up to 500
meters. The GBIC-LW supports 9-micron, single-mode fibre cables with
the SC connector in lengths up to 10 kilometers.
The KGPSA-BC/CA PCI-to-Fibre Channel host bus adapters and the
HSG80 RAID controller support the 50-micron Gigabit Link Module
(GLM) for fibre connections. Therefore, only the 50-micron multimode
fibre optical cable is supported between the KGPSA and switch and the
switch and HSG80 for cluster configurations. You must install GBIC-SW
GBICs in the Fibre Channel switches for communication between the
switches and KGPSA or HSG80.
• A maximum of three cascaded switches is supported, with a maximum of
two hops between switches. The maximum hop length is 10 km longwave
single-mode or 500 meters via shortwave multimode Fibre Channel cable.
2–4 Hardware Requirements and Restrictions
Number of KGPSA-BC Adapters
Supported
2
4
4
1
2
4
a
32 (2 per DWLPB for throughput, 4
per DWLPB for connectivity)
32 (2 per DWLPB for throughput, 4
per DWLPB for connectivity)
