Table 5–2: MC2 Jumper Configuration (cont.)
Jumper:
J3: Window Size
J4: Page Size
J5: AlphaServer
8x00 Mode
5–4 Setting Up the Memory Channel Cluster Interconnect
Description: Example:
VH0: Pins 2 to 3
1 2 3
VH1: None needed;
store the jumper on
pin 1 or pin 3
1 2 3
512 MB: Pins 2 to 3
1 2 3
128 MB: Pins 1 to 2
1 2 3
8-KB page size (UNIX):
Pins 1 to 2
1 2 3
4-KB page size (not
used): Pins 2 to 3
1 2 3
8x00 mode selected:
a
Pins 1 to 2
1 2 3
8x00 mode not selected:
Pins 2 to 3
1 2 3
