Electrical Specifications
Table 3-6. Voltage and Current Specifications - Ultra Low Voltage Processors (Sheet 1 of 2)
Symbol Parameter
®
V Intel Pentium
CCD773
Processor, Ultra Low
Voltage,
773 Core VCC for
Enhanced Intel
SpeedStep
Technology Operating
Points:
1.3 GHz
1.2 GHz
1.1 GHz
1.0 GHz
900 MHz
800 MHz
600 MHz
V Pentium M Processor,
CCD753
Ultra Low Voltage,
753 Core VCC for
Enhanced Intel
SpeedStep
Technology Operating
Points:
1.2 GHz
1.1 GHz
1.0 GHz
900 MHz
800 MHz
600 MHz
V Pentium M Processor,
CCD733J
Ultra Low Voltage,
733J Core VCC for
Enhanced Intel
SpeedStep
Technology operating
points:
1.1 GHz
1.0 GHz
900 MHz
800 MHz
600 MHz
26
Min Typ Max
®
M
®
VID# VID# VID#I VID#
GTyp HTyp Typ J Typ
0.956 0.940 0.924 0.908
0.940 0.924 0.908 0.908
0.924 0.908 0.892 0.892
0.908 0.892 0.876 0.876
0.876 0.876 0.860 0.860
0.860 0.860 0.844 0.844
0.812 0.812 0.812 0.812
0.956 0.940 0.924 0.908
0.940 0.924 0.908 0.892
0.908 0.908 0.892 0.876
0.892 0.876 0.876 0.860
0.860 0.860 0.860 0.844
0.812 0.812 0.812 0.812
0.956 0.940 0.924 0.908
0.940 0.924 0.908 0.892
0.908 0.892 0.892 0.876
0.876 0.876 0.860 0.860
0.812 0.812 0.812 0.812
VID# VID#
Unit Note
K Typ L Typ
V 2, 3
0.892 0.876
0.892 0.876
0.876 0.860
0.860 0.860
0.860 0.844
0.844 0.844
0.812 0.812
V 2, 3
0.892 0.876
0.892 0.876
0.876 0.860
0.860 0.844
0.844 0.844
0.812 0.812
V 2, 3, 4
0.892 0.876
0.876 0.876
0.860 0.860
0.844 0.844
0.812 0.812
