5058-030
Base machine with add-ons
Callout
Part name
1
Exit tray 2
Note: Exit tray 2 is applicable to any configurations
except when a finisher is installed.
2
Optional 520-sheet tray (Tray 2)
3
Optional 520-sheet tray (Tray 2)
4
Optional 520-sheet tray (Tray 2)
5
Optional 2,000-sheet tandem-tray module
• 850-sheet tray (Tray 3)
• 1,150-sheet tray (Tray 4)
Service Manual
5-2
1
2
3
4
5
