Clearing Jammed Paper (Paper Feed Slot)

Troubleshooting
Troubleshooting
Problems Regarding Paper
Problems Regarding Paper
Clearing Jammed Paper (Paper Feed Slot) ......................................................................................................... 90
Clearing Jammed Roll Paper ...................................................................................................................................... 91
Clearing a Jammed Sheet, Fed Manually .............................................................................................................. 94
Roll paper cannot be inserted into the paper feed slot ................................................................................. 97
Cannot load sheets ........................................................................................................................................................ 97
Paper is not cut neatly ................................................................................................................................................. 97
Paper is not cut ............................................................................................................................................................... 97
Depression on the leading edge is left .................................................................................................................. 98
Margins are wide ............................................................................................................................................................. 98
Clearing Jammed Paper (Paper Feed Slot)
Clearing Jammed Paper (Paper Feed Slot)
Follow these steps to clear jams deep in the Paper Feed Slot
when you are clearing jams
Clear any jammed paper deep in the Paper Feed Slot
If paper is jammed deep in the Paper Feed Slot, remove the Roll Feed Unit and clear the paper jam as follows.
1
Turn the printer off before removing the Roll Feed Unit from the printer. (See "Removing the Roll Feed
Unit.")
→User's Guide
2
Remove the jammed paper from the Paper Feed
Slot.
3
Attach the Roll Feed Unit to the printer. (See "Installing the Roll Feed Unit.")
Remove scraps left in the Paper Feed Slot
Follow these steps to remove any scraps left in the Paper Feed Slot after you clear jammed sheets or roll paper.
1
Press the Load button.
2
Press ▲ or ▼ to select Manual Paper, and then press the OK button.
A menu for selection of the type of paper is displayed.
3
Select POP Board and press the OK button.
Instructions for feeding POP Board are now displayed on the Control Panel, but follow this procedure to
remove the jammed paper.
4
Open the Top Cover.
90
.
→P.90
or to remove any scraps left in the slot
→P.90
→User's Guide
