Paper Jam; Paper Loaded Askew; Paper Not Aligned With Right Guide - Canon imagePROGRAF iPF6400 Basic Manual

iPF6400
Cause
The Paper Feed Slot used to load the
sheet is different from the Paper Feed
Slot specified in Paper Source in the
printer driver.

Paper jam.

Paper jam.
Cause
A paper jam oc- 1.
Cut the paper on the upper side of the Paper Feed Slot.
curred in the
2.
Press the OK button.
printer during
3.
printing.
Remove the jammed paper.
(See "Clearing Jammed Paper (Paper Feed Slot).")
(See "Clearing Jammed Roll Paper.")
(See "Clearing a Jammed Sheet, Fed Manually.")
4.
Load the paper.
(See "Loading Rolls in the Printer.")
(See "Loading Sheets in the Feed Slot.")
5.
If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen, press the OK button.
Printing will resume, starting from the page on which the error occurred.

Paper loaded askew.

Paper loaded askew.
Paper loaded crooked was detected when the paper was advanced.
•
To disable this message (if it is displayed repeatedly despite reloading paper, for example), choose Off or Loose in the
Skew Check Lv. setting of the printer menu. However, this may cause jams and printing problems because paper may
Important
be askew when printed. Also, the Platen may become soiled, which may soil the back of the next document when it is
printed.

Paper not aligned with right guide.

Paper not aligned with right guide.
Skew Check Lv. on the Control Panel menu is set to something other than Off and
the paper is not aligned with the guide on the right during loading.
Basic Guide
2.
Load the paper in the Paper Feed Slot specified in the printer driver.
The printer will resume printing.
Change the printer driver Paper Source setting to match the Paper Feed Slot where the
sheet is loaded as follows.
1.
Press ▲ or ▼ to select Stop Printing, and then press the OK button.
2.
In the printer driver, change the Paper Source setting to match the Paper Feed Slot where
the sheet is loaded, and then resend the print job.
→P.91
→P.11
→P.17
Cause
Cause
Corrective Action
Corrective Action
→P.90
→P.94
Corrective Action
Press the OK button and reload the paper.
(See "Loading Rolls in the Printer.")
(See "Loading Sheets in the Feed Slot.")
→P.17
If this error recurs after you reload the roll,
remove the Roll Holder from the printer,
push the roll firmly in until it touches the Roll
Holder flange, and reload the Roll Holder in
the printer.
(See "Loading Rolls on the Roll Holder.")
→P.9
Follow these steps to reload the sheet.
1.
Press the OK button to clear the error.
2.
Reload the paper.
(See "Loading Sheets in the Feed Slot.")
Paper jam.
→P.11
Corrective Action
→P.17
125
