Loading Rolls in the Printer
1
Press the Load button.
2
Press ▲ or ▼ to select Roll Paper, and then press the OK button.
•
Note
3
Open the Roll Feed Unit Cover.
4
Holding the Roll Holder flange (a), load the Roll
Holder shaft into the guide grooves (b) on both
sides of the Roll Holder Slot. At this time, load the
shaft so that the color of the Roll Holder shaft (c)
matches the color of the guide groove.
•
Caution
•
Important
12
→User's Guide (HTML)
If any paper has been advanced that will not be used, a message is shown requesting you to remove it.
Press ▲ or ▼ to select "Yes", and then press the OK button. Remove the paper and go to the next step.
Do not release the flanges until you load the holder fully in the Roll Holder Slot. Rolls are heavy, and dropping
a roll may cause injury.
Be careful not to pinch your fingers between the guide grooves (b) and the Roll Holder shaft (c) when loading
rolls.
•
Do not force the Roll Holder into the printer with the right and left ends reversed. Otherwise, it may damage
the printer or Roll Holder.
