Ethernet Connection

In terms of data transfer speed, the Ethernet provides the fastest mode of connection
between the router and the computer.
To connect through Ethernet:
1. Plug one end of the telephone cable from the POTS Splitter's ADSL port and then
plug the other end into the router's DSL port
POTS Splitter
A phone line can carry phone call and Internet signals. When you enable the phone
line for high speed Internet, the connection produces high-pitched tones when using
the phone. Installing a Plain Old Telephone Service (POTS) splitter separates the two
signals and eliminates the noise.
To setup the telephone POTS Splitter:
1. Locate the phone jack in your house.
2. Insert the POTS Splitter into the phone jack.
3. Plug one end of the telephone cable from the POTS Splitter's TEL port and then plug
the other end into the telephone.
2. Plug one end of the Ethernet cable from the router's ETHERNET port and then plug
the other end into the Ethernet port in your computer.
3. Connect the power adapter from the router's 9V DC port into the electrical outlet
and then press ON.
